Registers – Read Operation
Reg. No. Name Description
00H No error
01H Drive over current (OC)
02H Over voltage (OE)
03H Drive overheat (OH)
04H ad (OL1)(OL2) Drive overlo
05H Motor overload (OL)
06H External fault (EF)
07H Short protection (SC)
08H A/D converter error (AdEr)
09H Reserved
0AH Reserved
0BH Reserved
2100H Drive error code
0CH Reserved
0DH Grounding fault (GF)
0EH Under voltage during operation (LE1)
0FH EEPROM error (EEr)
10H Reserved
11H Drive output interruption (bb)
12H O) System overload (OL
13H Reserved
14H Reserved
15H
Coast to stop (Fr)
b0~b7 Reserved
b8 by communication1: Frequency control
b9 by analog inputs 1: Frequency control
bA 1: Operation command by communication
bB r locking 1: Paramete
bC 1: Drive running status
bD 1: Jog running status
bE 1: Forward indication
2101H Drive status 1
indication bF 1: Reverse
2102H
Frequency command Monitor drive’s frequency command (unit: 0.01Hz)
2103H
Output frequency Monitor drive’s output frequency(unit: 0.01Hz)
2104H
Output current Monitor drive’s output current(unit: 0.1A)
2105H
DC bus voltage M it: 0.1V) onitor drive’s DC bus voltage(un
2106H
Output voltage M voltage(unit: 0.1V) onitor drive’s AC output
2107H
Frequency of
multi-speed
M
*N
onitor drive’
s frequency of multi-speed
ote 2
2108H
Reserved
2109H
Reserved
210AH
Reserved
210BH
Reserved
210CH
Reserved
210DH
Reserved
