210EH
Reserved
210FH
Reserved
b0 Reserved
b1 Reserved
b2 1: X1 terminal operation
b3 1: X2 terminal operation
b4 1: X3 terminal operation
b5 1: X4 terminal operation
b6 Reserved
b7 Reserved
b8 1: Y1 terminal detection
b9
Reserved
bA
Reserved
bB
Reserved
bC 1: Primary
2300H
I/O terminal st
atus
speed by analog input
bD 1: Primary speed by operation panel
bE 1: Primary speed by UP/DOWN command
bF 1: Primary speed by communication
b0 Reserved
b1 1: Constant speed
b2 1: Zero speed
b3 1: Frequency detection
b4 1: System overload
b5 1: Stall prevention
b6 Reserved
b7 1: Braking action
b8 Reserved
b9 Reserved
bA 1: Error signal
2301H Drive status 2
bB~bF Reserved
2302H
Rese rved
2303H
Fault record 1 F eault r cord 1
*Note 3
2304H
Fault record 2 F eault r cord 2
*Note 3
2305H
Fault record 3 Fa eult r cord 3
*Note 3
2306H
Fault record 4 Fault record 4
*Note 3
2307H
Fault record 5 Fault record 5
*Note 3
