TK 61753-2-MM-EN
71
Figure 19. Shown in low idle position – solenoid de-energized
1. Engine Throttle
2. LS Stop Screw – adjustable
Low idle stop screw can be adjusted to increase/decrease low idle RPM setting.
The HMI will instruct the technician to increase, decrease or tighten stop screw position.
EEnnggiinnee MMaaiinntteennaannccee
