Table 1. Installation requirements (continued)
Requirement Trane Supplied, Trane Installed Trane Supplied, Field Installed Field Supplied, Field Installed
Electrical
• Circuit breakers or non-fused
disconnects (optional)
• Unit-mounted starter
• Circuit breaker or non-fused
disconnect handle
• Temperature sensor (optional
outdoor air)
• Flow switches (may be field-
supplied)
• Condenser water regulating
valve controller (optional: may
be field-supplied)
• Circuit breakers or fusible
disconnects (optional)
• Terminal lugs
• Ground connection(s)
• Jumper bars
• BAS wiring (optional)
• IPC wiring
• Control voltage wiring
• High condenser pressure
interlock wiring
• Chilled water pump contactor
and wiring
• Condenser water pump
contactor and wiring
• Optional relays and wiring
Water piping
Pressure Relief Relief valves Vent line and flexible connector
Insulation
Insulation (optional)
Insulation
Optimus™ RTHD Installation
Completion Check Sheet and
Request for Trane Service (RLC-
ADF005*-EN, see “Log and Check
Sheets,” p. 85)
Chiller Start-up Commissioning
(b)
Trane, or an agent of Trane
specifically authorized to perform
start-up of Trane® products
(a)
Trane, or an agent of Trane specifically authorized to perform start-up and warranty of Trane® products, will perform or have direct on-site supervision of the disassembly
and reassembly work.
(b)
Start-up must be performed by Trane or an agent of Trane specifically authorized to perform start-up and warranty of Trane® products. Contractor shall provide Trane (or an
agent of Trane specifically authorized to perform start-up) with notice of the scheduled start-up at least two weeks prior to the scheduled start-up.
Pre-Installation
