Trane Optimus RTHD - Condenser Pressure Drop Charts; Water Piping Setup

RTHD-SVX01L-EN
27
Water Piping
Figure 13. Typical water piping setup
Evap
Water
Flow
Shutoff
Valves
Isolation
Valves
Manifold
Flow
Switch
Thermometers
Pressure
Differential
Gauge
Relief
Valve
Cond Water
Ref Valve (Opt)
Cond
Water
Flow
Shutoff
Valves
Isolation
Valves
Manifold
Flow
Switch
Thermometers
Pressure
Differential
Gauge
Relief
Valve
Installation Mechanical
