Trane Optimus RTHD - Operator Log Data Entry

RTHD-SVX01L-EN
89
Operator Log
Chiller Log
Run Time
Main Tab 15 min 30 min 1 hr
Chiller Mode
Evaporator Ent/Lvg Water Temp
Condenser Ent/Lvg Water Temp
Active Chilled Water Setpoint (°F)
Average Motor Current (%RLA)
Active Demand Limit Setpoint (%)
Software Type
Software Version
Reports Tab
Evaporator
Evaporator Entering Water Temperature (°F)
Evaporator Leaving Water Temperature (°F)
Evaporator Saturated Refrigerant Temp (°F)
Evaporator Refrigerant Pressure (psia)
Evaporator Approach Temp (°F)
Evaporator Water Flow Status
EXV Percent Open (%)
EXV Position Steps
Evaporator Refrigerant Liquid Level (in.)
Condenser
Condenser Entering Water Temperature (°F)
Condenser Leaving Water Temperature (°F)
Condenser Saturated Refrigerant Temp (°F)
Condenser Refrigerant Pressure (psia)
Condenser Approach Temp (°F)
Condenser Water Flow Status
Head Pressure Control Command (%)
Compressor
Compressor Starts
Compressor Running Time
Differential Refrigerant Pressure (psid)
Compressor Oil Pressure (psia)
Compressor Discharge Temp (°F)
Compressor Discharge Superheat (°F)
Motor Current % RLA L1 L2 L3 (%)
