RTHD-SVX01L-EN
37
Table 9. Compressor motor electrical data (60 Hz) — standard units (wye-delta starter) (continued)
Compressor Code
(a)
Voltage
(b)
Max kW
RLA @
Max kW
(c)
LRA
(Wye)
LRA
(Delta)
D1, D2
200 329 1047 1690 5477
230 329 918 1532 4966
380 329 549 850 2755
460 329 455 730 2366
575 329 367 612 1984
(a)
Unit model number digits 6 and 7.
(b)
Voltage utilization ranges: 200V (180-220)m 230V (205-254), 380V (342-418), 460V (414-506), 575V (516-633).
(c)
The RLA @ Max kW is based on the performance of the motor developing full rated horsepower.
Electrical Data Table Information
Compressor motor electrical data is provided in Table 9, p.
36 for each compressor size. Rated load amperes (RLA),
locked rotor wye amperes (LRA) and expected inrush for
the Wye-delta configurations are shown.
Although the terms “LRA” and “expected inrush” are often
used interchangeably, the distinction applied here is that
LRA is the rated inrush for the motor, but expected inrush is
that allowed by the starter, based on the specific
configuration. Selecting starters in the Wye-delta
configuration lowers expected inrush vs. the across-the-
line configuration.
The RLA is based on the motor’s performance when
reaching full rated horsepower. The kW rating of the motor
will equal or exceed the kW requirement indicated by the
Trane® Select Assist™ selection program at design
conditions. If motor kW draw at design conditions is less
than the kW rating of the motor, the RLA at design
conditions is determined by multiplying the motor RLA (at
the desired voltage) by this ratio: design kW/ motor kW
rating. This calculation is performed within the computer
selection program, making RLA available as part of the
design predictions. Predicted values include power factor
variation from point to point.
Optimus™ chillers are designed to operate satisfactorily
over a utilization range of ±10 percent of the standard
design voltages: 200V, 230V, 380V, 460V, and 575V for 60
Hertz, 3-phase.
Units with AFD Option
Table 10. Electrical data - units with AFD
Voltage Applied Range
(a)
Estimated Power Loss (W)
575V 60 Hz
0 - 126 1739
127 - 150 2099
151 - 185 2646
186 - 234 3071
235 - 279 3719
280 - 316 4460
317 - 366 5023
460V 60 Hz
0 - 176 2257
177 - 223 2719
224 - 280 3622
281 - 335 3561
336 - 411 4558
412 - 455 5703
380V 60 Hz
0 - 197 2555
198 - 241 2949
242 - 292 3764
293 - 367 4109
368 - 446 5129
447 - 549 6663
Note: AFD input amps are shown in the RLA field of the unit nameplate.
(a)
Model number digits 56-58.
Installation Electrical
