16
RTHD-SVX01L-EN
Table 3. Weights — units with AFD option (continued)
Unit Configuration
(a)
Shipping Weight Operating Weight
AFD D1H Frame AFD D2H Frame AFD D1H Frame AFD D2H Frame
lbs
kg
lbs
kg
lbs
kg
lbs
kg
C1E1F1 14949 6781 15088 6844 16801 7621 16940 7684
C2D3E3 14235 6457 14374 6520 15278 6930 15417 6993
C2D4E4 13206 5990 13344 6053 13907 6308 14046 6371
C2F2F3 17055 7736 17194 7799 18446 8367 18585 8430
D1D1E1 – – 14815 6720 – – 15756 7147
D1F1F2 – – 16559 7511 – – 17910 8124
D1G1G1 – – 18973 8606 – – 20873 9468
D1G2G2 – – 19480 8836 – – 21438 9724
D2D2E2 – – 14934 6774 – – 15944 7232
D2F2F3 – – 17194 7799 – – 18594 8434
D2G2G1 – – 19072 8651 – – 21074 9559
D2G3G3 – – 19881 9018 – – 22013 9985
D3D2E2 – – 14934 6774 – – 15944 7232
D3F2F3 – – 17194 7799 – – 18594 8434
D3G2G1 – – 19023 8629 – – 21023 9536
E3D2E2 – – 15093 6846 – – 16100 7303
E3F2F3 – – 17337 7864 – – 18728 8495
E3G2G1 – – 19173 8697 – – 21173 9604
E3G3G3 – – 20036 9088 – – 22169 10056
Notes:
1. Weights vary with AFD frame size. D1H frame size used on units with model number digit 44 = G, H, J, V, W, X, 2, 3, or 4. D2H frame size used with model number
digit 44 = K, L, M, N, Y, Z, 1, 5, 6, or 7.
2. All weights +/- 3%.
3. Shipping weights include standard 150 psig water boxes, refrigerant charge and oil charge.
4. Operating weights include refrigerant, oil and water charges.
5. AFD frame size determined by unit selection. See submittal for information.
(a)
Unit configuration digits 1, 2 - compressor code (also shown in unit model number digits 6, 7); digits 3, 4 - evaporator code (unit model number digits 14, 15); digits 5, 6 -
condenser code (unit model number digits 21, 22).
Unit Dimensions
See unit submittals for specific unit dimensions and water
connection locations.
Service Clearances
Notes:
• Required vertical clearance above unit is 36-
inch (914 mm). There should be no piping or
conduit located over the compressor motor.
• Maximum clearances are given. Some units
configurations may require less clearance than
others in the same category.
• If the room configuration requires a variance to
the clearance dimensions, contact your Trane
sales office representative.
Dimensions and Weights
