Trane Optimus RTHD - Dimensions and Weights; Unit Weights (Standard and AFD)

RTHD-SVX01L-EN
15
Dimensions and Weights
Unit Weights
Table 2. Weights — standard units (wye-delta starter)
Unit Configuration
(a)
Shipping Weight Operating Weight
lbs
kg
lbs
kg
B1B1B1 9292 4215 9867 4476
B1C1D1 9837 4462 10554 4787
B2B2B2 9402 4265 10019 4545
B2C2D2 9953 4515 10653 4832
C1D5E4 12973 5884 13673 6202
C1D6E5 12780 5797 13397 6077
C1E1F1 14718 6676 15818 7175
C2D3E3 14002 6351 15044 6824
C2D4E4 12972 5884 13672 6201
C2F2F3 16168 7334 17560 7965
D1D1E1 14443 6551 15385 6987
D1F1F2 16187 7342 17537 7955
D1G1G1 18600 8437 20500 9299
D1G2G2 19107 8667 21065 9555
D2D2E2 14562 6605 15570 7062
D2F2F3 16820 7629 18220 8264
D2G2G1 18700 8482 20700 9389
D2G3G3 19508 8849 21641 9816
D3D2E2 14562 6605 15570 7062
D3F2F3 16820 7629 18220 8264
D3G2G1 18650 8460 20650 9367
E3D2E2 14720 6677 15728 7134
E3F2F3 16956 7691 18356 8326
E3G2G1 18800 8528 20800 9435
E3G3G3 19653 8915 21786 9882
Notes:
1. All weights +/- 3%
2. Shipping weights include standard 150 psig water boxes, refrigerant charge and oil charge.
3. Operating weights include refrigerant, oil and water charges.
(a)
Unit configuration digits 1, 2 - compressor code (also shown in unit model number digits 6, 7); digits 3, 4 - evaporator code (unit model number digits 14, 15); digits 5, 6 -
condenser code (unit model number digits 21, 22).
Table 3. Weights — units with AFD option
Unit Configuration
(a)
Shipping Weight Operating Weight
AFD D1H Frame AFD D2H Frame AFD D1H Frame AFD D2H Frame
lbs
kg
lbs
kg
lbs
kg
lbs
kg
B1B1B1 9526 4321 9664 4384 10101 4582 10239 4645
B1C1D1 10071 4568 10209 4631 10787 4893 10925 4956
B2B2B2 9636 4371 9774 4434 10251 4650 10389 4713
B2C2D2 10187 4621 10325 4684 10886 4938 11024 5001
C1D5E4 13206 5990 13344 6053 13904 6307 14043 6370
C1D6E5 13014 5903 13153 5966 13631 6183 13770 6246
