Trane Optimus RTHD - Lifting Points and Dimensions

RTHD-SVX01L-EN
19
Figure 6. Lifting location point weights and dimensions
Y
Z
A
B
C
D
X
= C.G.
Note: Optional AFD is not shown. See Figure 3, p. 11 for location of optional AFD. Lifting weights and center of gravity
measurements are shown for both unit configurations in tables below.
Installation Mechanical
