RTHD-SVX01L-EN
3
WARNING
Follow EHS Policies!
Failure to follow instructions below could result in
death or serious injury.
• All Trane personnel must follow the company’s
Environmental, Health and Safety (EHS) policies
when performing work such as hot work,
electrical, fall protection, lockout/tagout,
refrigerant handling, etc. Where local
regulations are more stringent than these
policies, those regulations supersede these
policies.
• Non-Trane personnel should always follow local
regulations.
WARNING
Refrigerant under High Pressure!
Failure to follow instructions below could result in an
explosion which could result in death or serious
injury or equipment damage.
System contains refrigerant under high pressure.
Recover refrigerant to relieve pressure before
opening the system. See unit nameplate for
refrigerant type. Do not use non-approved
refrigerants, refrigerant substitutes, or refrigerant
additives.
Factory Warranty Information
Compliance with the following is required to preserve the
factory warranty:
All Unit Installations
Startup MUST be performed by Trane, or an authorized
agent of Trane, to VALIDATE this WARRANTY. Contractor
must provide a two-week startup notification to Trane (or an
agent of Trane specifically authorized to perform startup).
Additional Requirements for Units Requiring
Disassembly
When a new fully assembled chiller is shipped and
received from our Trane manufacturing location, and, for
any reason, it requires disassembly or partial disassembly
• which could include but is not limited to the evaporator,
condenser, control panel, compressor/motor, or any
other components originally attached to the fully
assembled unit.
• compliance with the following is required to preserve
the factory warranty:
– Trane, or an agent of Trane specifically authorized
to perform startup and warranty of Trane®
products, will perform or have direct onsite
technical supervision of the disassembly and
reassembly work.
– The installing contractor must notify Trane — or an
agent of Trane specifically authorized to perform
startup and warrant of Trane products — two weeks
in advance of the scheduled disassembly work to
coordinate the disassembly and reassembly work.
– Startup must be performed by Trane or an agent of
Trane specifically authorized to perform startup and
warranty of Trane products as noted above.
Trane, or an agent of Trane specifically authorized to
perform startup and warranty of Trane® products, will
provide qualified personnel and standard hand tools to
perform the disassembly work at a location specified by the
contractor. The contractor shall provide the rigging
equipment such as chain falls, gantries, cranes, forklifts,
etc. necessary for the disassembly and reassembly work
and the required qualified personnel to operate the
necessary rigging equipment.
Copyright
This document and the information in it are the property of
Trane, and may not be used or reproduced in whole or in
part without written permission. Trane reserves the right to
revise this publication at any time, and to make changes to
its content without obligation to notify any person of such
revision or change.
Trademarks
All trademarks referenced in this document are the
trademarks of their respective owners.
Revision History
• Updated the Model Number Descriptions, General
Data, Maintenance, Diagnostics chapter.
• Added Air-Fi and Wi-Fi topics in Controls chapter.
• Removed the Electrical chapter.
• Updated the Service Clearance section in the
Dimensions and Weights chapter.
• Updated the Wiring drawing number for wye-delta units
in the Wiring Chapter.
