Trane Optimus RTHD - AFD Drive Parameter Settings

46
RTHD-SVX01L-EN
Table 13. Non-compressor specific parameter
settings
ID
Description Setting
0-03
Region Settings
North American
0-20
Display Line 1.1 Small DC Link Voltage
0-22
Display Line 1.3 Heatsink Temp.
0-24
Display Line 3 Large Analog Input 53
0-40
[Hand on] Key on LCP
Disabled
0-41
[Off] Key on LCP
Disabled
0-60 Main Menu Password 999
0-61
Access to Main Menu w/o
Password
Read Only
1-03
Torque Characteristics Compressor Torque
1-71
Start Delay
0s
1-73
Flying Start
Disabled
1-78
Compressor Start Max Speed
[Hz]
20Hz
1-79
Compressor Start Max Time to
Trip
10s
1-87
Trip Speed Low [Hz]
25Hz
3-02 Min Reference 30Hz
3-41
Ramp 1 Ramp up Time
10s
3-42
Ramp 1 Ramp Down Time
10s
3-82
Starting Ramp Up Time
5s
4-10
Motor Speed Direction
Clockwise
Table 13. Non-compressor specific parameter
settings (continued)
ID
Description Setting
4-12
Motor Speed Low Limit [Hz]
30Hz
4-18 Current Limit Max
5-02 Terminal 29 Mode
Output
5-12
Terminal 27 Digital Input
Coast Inverse
5-31
Terminal 29 Digital Output
Alarm
5-40
Function Relay 1 No Operation
6-10
Terminal 53 Low Voltage
2V
6-14
Terminal 53 Low Ref./Feedb.
Value
30Hz
6-50
Terminal 42 Output
Power 4-20mA
14-00
Switching Pattern
SFAVM
14-03 Overmodulation Off
14-10 Mains Failure
[4] Kinetic Back-Up
14-12 Function at Mains Imbalance Derate
14-21 Automatic Restart Time 8s
14-50 RFI Filter Off
14-51
DC Link Compensation
On
14-60
Function at Over Temperature
Derate
14-61 Function at Inverter Overload Derate
14-62 Inv. Overload Derate Current 1
Table 14. Compressor-specific parameter settings
Parameters B1/B2 Motor Frame C1/C2 Motor Frame D1/D2/D3 Motor Frame
E3
Motor
Frame
ID
Description
460/60 400/50 380/60 575/60 460/60 400/50 380/60 575/60 460/60 400/50 380/60 575/60 400/50
1-21
Motor Power (hp)
233 194 233 233 334 280 334 334 441 375 441 441 403
1-22
Motor Voltage
(V)
460 400 380 575 460 400 380 575 460 400 380 575 400
1-23
Motor Frequency
(Hz)
60 50 60 60 60 50 60 60 60 50 60 60 50
1-24
Motor Current
(A)
241 233 291 193 349 349 421 279 455 455 549 367 488
1-25
Motor Nominal
Speed (rpm)
3512 2921 3512 3512 3531 2938 3531 3531 3535 2943 3535 3535 2943
1-30
Stator
Resistance
(ohms)
0 0.0303 0.0213 0.043 0.0201 0.0201 0.0138 0.0308 0.0122 0.0122 0.0087 0.0197 0.0122
1-31
Rotor Resistance
(ohms)
0 0.0257 0.0179 0.0365 0.0146 0.0146 0.0103 0.0227 0.0091 0.0091 0.0066 0.0144 0.0091
1-35
Main Reactance
(ohms)
5 5.3684 3.9634 8.057 3.005 3.005 2.1972 4.8857 2.8882 2.8882 2.1848 4.8553 2.8882
Installation Electrical
