Installation, Operation and Maintenance 1 - 3
Voltage
200/60/3 A
8
230/60/3 C
380/60/3 D
380/50/3 R
400/50/3 N
415/50/3 U
460/60/3 F
575/60/3 H
Specials
None O 9
Specials denoted elsewhere C
Specials not denoted elsewhere S
Design
Sequence
First Design (Factory Input) AO 10-11
Evaporator
Frame
B Frame B
12
C Frame C
D Frame D
E Frame E
F Frame F
G Frame G
Evaporator
Capacity
Tube count #1 1 13
Tube count #2 2
Tube count #3 3
Evaporator
Waterside
Pressure
150 psi L 14
300 psi H
Evaporator
Water Pass
Configuration
2 pass 2 15
3 pass 3
4 pass 4
Condenser
Frame
B Frame B
16
C Frame C
D Frame D
E Frame E
F Frame F
G Frame G
Condenser
Capacity
Tube count #1 1 17
Tube count #2 2
Tube count #3 3
Condenser
Waterside
Pressure
150 psi L 18
300 psi H
Condenser
Tubes
Enhanced Fin Copper F 19
Smooth Bore Copper G
Smooth Bore 90/10 Cu/Ni H
Table 1
Model Number for RTHC Chiller
Selection
Category
Description of Selection Model No. Digit
