Installation, Operation and Maintenance 1 - 7
Figure 2
Component Location for Typical RTHC Unit
Starter/Control Panel
Evaporator
Evaporator
Water Inlet
Evaporator
Nameplate
Condenser
Water Inlet
Condenser
Water Outlet
Liquid/Vapor
Separator
Clear Language
Display (CLD)
Gas Pump
Relief
Valve
Liquid Level
Sensor
EXV
Disconnect
Switch
NOTE: The evaporator inlets and outlets are located opposite from those on the RTHA and RTHB
units. The water inlet must be at the bottom of the shell for proper operation.
