Trane RTHC - Component Location for Typical RTHC Unit (Back View)

1 - 8 RTHC-IOM-1C
Figure 3
Component Location for Typical RTHC Unit (Back View)
Condenser
Compressor
Evaporator
Water Outlet
Oil Separator
Lifting
Holes
Relief
Valves
Discharge
Lines
Oil Distribution
System
Oil Separator
Unit Nameplate
(on side of starter/control
panel)
NOTE: The evaporator inlets and outlets are located opposite from those on the RTHA and RTHB
units. The water inlet must be at the bottom of the shell for proper operation.
Oil Sump
8” vessels have ASME nameplate
(located between condenser and evaporator)
