Trane RTHC - Unit Designator

Installation, Operation and Maintenance 1 - 11
Notes: All weights
± 3%, include standard 150 psig water boxes.
Operating weights include refrigerant, oil, and water charges.
If oil cooler is installed, add 1.0 gal (4 liters) to the oil charge value given
* Overall dimensions are based on 3-pass evap/2 pass cond and LH/RH water connections. Refer to submittals for exact job configurations
Maximum Flow (gpm (l/s))
1666 (105)
for 2-pass
2292 (144)
for 2-pass
2221 (140)
for 3-pass
1827 (115)
for 2-pass
2453 (154)
for 2-pass
2531 (154)
for 3-pass
1111 (70)
for 3-pass
1528 (96)
for 3-pass
1666 (72)
for 4-pass
1218 (72)
for 3-pass
1636 (103)
for 3-pass
1898 (119)
for 4-pass
Condenser (all are 2-pass)
Water Storage (gal (l))
44 (166) 57 (216) 91 (344) 47 (178) 61 (231) 97 (367)
Minimum Flow (gpm (l/s))
348 (22) 425 (27) 644 (40) 380 (24) 463 (29) 708 (45)
Maximum Flow (gpm (l/s))
1276 (80) 1558 (98) 2360 (148) 1392 (88) 1699 (107) 2597 (164)
Table 6
General Data
Unit Designator (corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
D3D2E2 D3F2F3 D3G3G3 E3D2E2 E3F2F3 E3G3G3
General
Refrigerant Type
HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a
Refrigerant Charge (lb (kg))
575 (261) 740 (336) 850 (385) 575 (261) 740 (336) 850 (385)
Oil Charge (gal (l))
6 (23) 10 (35) 11 (39) 6 (23) 10 (35) 11 (39)
Operating Weight (lb (kg))
15,900 (7189) 18,700 (8482) 22,100(10,024) 16,150 (7326) 18,950 (8596) 22,350 (10,138)
Shipping Weight (lb (kg))
15,000 (6804) 17,400 (7892) 20,100 (9117) 15,250 (6917) 17,650 (8006) 20,350 (9231)
Overall Dimensions
Length (in (mm))
134 (3404) 149 (3785) 153 (3886) 137 (3480) 149 (3785) 153 (3886)
Width (in (mm))
69 (1753) 69 (1753) 70 (1778) 69 (1753) 69 (1752) 70 (1778)
Height (in (mm))
76 (1930) 76 (1930) 80 (2032) 76 (1930) 76 (1930) 80 (2032)
Evaporator
Water Storage (gal (l))
74 (280) 107 (405) 159 (602) 74 (280) 107 (405) 159 (602)
Minimum Flow (gpm (l/s))
498 (31) for
2-pass
669 (42) for
2-pass
690 (43) for
3-pass
498 (31) for
2-pass
669 (42) for
2-pass
690 (43) for
3-pass
332 (21) for
3-pass
446 (28) for
3-pass
518 (33) for
4-pass
332 (21) for
3-pass
446 (28) for
3-pass
518 (33) for
4-pass
Maximum Flow (gpm (l/s))
1827 (115)
for 2-pass
2453 (154)
for 2-pass
2531 (154)
for 3-pass
1827 (115)
for 2-pass
2453 (154)
for 2-pass
2531 (154)
for 3-pass
1218 (72)
for 3-pass
1636 (103)
for 3-pass
1898 (119)
for 4-pass
1218 (72)
for 3-pass
1636 (103)
for 3-pass
1898 (119)
for 4-pass
Condenser (all are 2-pass)
Water Storage (gal (l))
47 (178) 61 (231) 97 (367) 47 (178) 61 (231) 97 (367)
Minimum Flow (gpm (l/s))
380 (24) 463 (29) 708 (45) 380 (24) 463 (29) 708 (45)
Maximum Flow (gpm (l/s))
1392 (88) 699 (107) 597 (164) 1392 (88) 699 (107) 597 (164)
Table 5
General Data
Unit Designator (corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
D1D1E1 D1F1F2 D1G2G2 D2D2E2 D2F2F3 D2G3G3
