Notes: All weights
± 3%, include standard 150 psig water boxes.
Operating weights include refrigerant, oil, and water charges.
If oil cooler is installed, add 1.0 gal (4 liters) to the oil charge value given
* Overall dimensions are based on 3-pass evap/2 pass cond and LH/RH water connections. Refer to submittals for exact job configurations
Table 7
General Data
Unit Designator (corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
C1B2C1 C1B3C2 C1E1F1 C2B3C2 C2D3E3
General
Refrigerant Type
HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a
Refrigerant Charge (lb (kg))
420 (191) 420 (191) 600 (272) 420 (191) 575 (261)
Oil Charge (gal (l))
6 (23) 6 (23) 10 (35) 6 (23) 6 (23)
Operating Weight (lb (kg))
13,900 (6307) 14,250 (6466) 16,700 (7574) 14,175 (6430) 15,550 (7055)
Shipping Weight (lb (kg))
13,300 (6034) 13,600 (6171) 15,600 (7076) 13,500 (6124) 14,600 (6624)
Overall Dimensions
Length (in (mm))*
129 (3277) 129 (3277) 145 (3683) 129 (3277) 129 (3277)
Width (in (mm))*
68 (1727) 68 (1727) 68 (1727) 68 (1727) 68 (1727)
Height (in (mm))*
72 (1829) 72 (1829) 76 (1930) 72 (1829) 76 (1930)
Evaporator
Water Storage (gal (l))
45 (170) 52 (197) 82 (311) 52 (197) 78 (295)
Minimum Flow (gpm (l/s))
319 (20) for
2-pass
386 (24) for
2-pass
499 (31) for
2-pass
386 (24) for
2-pass
542 (34) for
2-pass
213 (13) for
3-pass
257 (16) for
3-pass
332 (21) for
3-pass
257 (16) for
3-pass
362 (23) for
3-pass
Maximum Flow (gpm (l/s))
1171 (74) for
2-pass
1413 (89) for
2-pass
1827 (115) for
2-pass
1413 (89) for
2-pass
1989 (125) for
2-pass
781 (49) for
3-pass
942 (59) for
3-pass
1218 (77) for
3-pass
942 (59) for
3-pass
1326 (84) for
3-pass
Condenser (all are 2-pass)
Water Storage (gal (l))
29 (110) 32 (121) 50 (189) 32 (121) 47 (178)
Minimum Flow (gpm (l/s))
248 (16) 293 (18) 450 (28) 293 (18) 387 (24)
Maximum Flow (gpm (l/s))
908 (57) 1074 (68) 1640 (103) 1074 (68) 1421 (90)
Unit Designator (corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
C2G1G1 B1B1B1 B1C1D1 B2B2B2 B2C2D2
General
Refrigerant Type
HFC-134a HFC-134a HFC-134a HFC-134a HFC-134a
Refrigerant Charge (lb (kg))
850 (386) 410 (186) 450 (204) 410 (186) 450 (204)
Oil Charge (gal (l))
11 (39) 4.5 (17.0) 4.5 (17.0) 4.5 (17.0) 4.5 (17.0)
Operating Weight (lb (kg))
20,150 (9142) 10,250 (4649) 11,000 (4990) 10,400 (4717) 11,200 (5080)
Shipping Weight (lb (kg))
18,500 (8394) 9700 (4400) 10,300 (4672) 9800 (4445) 10,450 (4740)
Overall Dimensions
Length (in (mm))*
149 (3785) 125 (3175) 143 (3632) 125 (3175) 143 (3632)
Width (in (mm))*
70 (1778) 65 (1651) 65 (1651) 65 (1651) 65 (1651)
Height (in (mm))*
80 (2032) 71 (1803) 71 (1803) 71 (1803) 71 (1803)
Evaporator
