Installation, Operation and Maintenance 1 - 13
Notes: All weights
±
3%, include standard 150 psig water boxes.
Operating weights include refrigerant, oil, and water charges.
If oil cooler is installed, add 1/4 gal (1 liter) to the oil charge value given for B family units; add 1.0 gal (4 liters) for all other units.
* Overall dimensions are based on 3-pass evap/2 pass cond and LH/RH water connections. Refer to submittals for exact job configurations
Water Storage (gal (l))
136 (515) 41 (155) 55 (208) 45 (170) 58 (220)
Minimum Flow (gpm (l/s))
558 (35) for
3-pass
275 (17) for
2-pass
352 (22) for
2-pass
319 (20) for
2-pass
385 (24) for
2-pass
419 (26) for
4-pass
184 (12) for
3-pass
234 (15) for
3-pass
213 (13) for
3-pass
257 (16) for
3-pass
Maximum Flow (gpm (l/s))
2046 (129) for
3-pass
1010 (64) for
2-pass
1292 (82) for
2-pass
1171 (74) for
2-pass
1414 (89) for
2-pass
1535 (96) for
4-pass
673 (42) for
3-pass
862 (54) for
3-pass
781 (49) for
3-pass
942 (59) for
3-pass
Condenser (all are 2-pass)
Water Storage (gal (l))
79 (299) 28 (114) 31 (117) 29 (110) 34 (129)
Minimum Flow (gpm (l/s))
553 (34) 232 (15) 232 (15) 254 (16) 254 (16)
Maximum Flow (gpm (l/s))
1956 (123) 852 (54) 852 (54) 933 (59) 933 (59)
Unit Designator
(corresponds to digits 6, 7, 12, 13, 16, 17 of unit model number)
C2G1G1 B1B1B1 B1C1D1 B2B2B2 B2C2D2
