Installation, Operation and Maintenance 1 - 9
Installation Overview
For convenience,
Table 4
summarizes
responsibilities that are typically associated with the
RTHC chiller installation process.
Refer to the Installation Mechanical and Installation
Electrical sections of this manual for detailed
installation instructions.
q Locate and maintain the loose parts, e.g.
isolators, temperature sensors, flow sensors or
other factory-ordered, field-installed options, for
installation, as required. Loose parts are located
in the starter/control panel.
q Install the unit on a foundation with flat support
surfaces, level within 1/4” (6.35 mm) and of
sufficient strength to support concentrated
loading. Place the manufacturer-supplied isolation
pad assemblies under the unit.
q Install the unit per the instructions outlined in the
Mechanical Installation section.
q Complete all water piping and electrical
connections.
Table 4
Installation Responsibility Chart for RTHC Units
Requirement Trane-supplied, Trane-installed Trane-supplied, Field-installed Field-supplied, Field-installed
Rigging
Safety chains
Clevis connectors
Lifting beam
Isolation
Isolation pads Isolation pads
Electrical
Circuit breakers or non-fused
disconnects (optional)
Circuit breakers or fusible
disconnects (optional)
Unit-mounted starter Temperature sensor (optional
outdoor air)
Terminal lugs
Flow switches (may be field-
supplied)
Ground connection(s)
Condenser water regulating valve
controller (optional: may be field-
supplied)
Jumper bars
BAS wiring (optional)
IPC wiring
Control voltage wiring
High condenser pressure interlock
wiring
Chilled water pump contactor and
wiring
Condenser water pump contactor
and wiring
Optional relays and wiring
Water piping
Flow switches (may be field-
supplied)
Thermometers
Condenser water regulating valve
controller (optional: may be field-
supplied)
Water flow pressure gauges
Isolation and balancing valves
water piping
Vents and drain valves
Pressure relief valves (for water
boxes as required)
Pressure Relief
Relief valves Vent line and flexible connector
Insulation
Insulation (optional) Insulation
