Trane RTHC - Evaporator and Condenser Data

2 - 16 RTHC-IOM-1C
*Note: Metric Conversion is
6 NPS = 150 mm nominal
8 NPS = 200 mm nominal
10 NPS = 250 mm nominal
Table 11
Evaporator and Condenser Data
Compressor
Frame Code
(Digit 6,7 of
Model No.)
Evap Shell Code
(Digits 12, 13 of
Model No.)
Evap. Shell
Diameter (in)
Nominal Connector size
(NPS)*
Cond Shell Code
(Digits 16,17 of
Model No.)
Cond. Shell
Diameter (in)
Nom.
Conn.
Size
(NPS)*
2-Pass 3-Pass 4-Pass 2-Pass
E3
D2 26.5 8 8 - E2 22.0 8
F2 29.0 8 8 - E2 22.0 8
G3 33.5 - 10 8 G3 25.75 8
D3
D2 26.5 8 8 - E2 22.0 8
F2 29.0 10 8 - F3 22.0 8
G3 33.5 - 10 8 G3 25.75 8
D2
D2 26.5 8 8 - E2 22.0 8
F2 29.0 10 8 - F3 22.0 8
G3 33.5 - 10 8 G3 25.75 8
D1
D1 26.5 8 8 - E1 22.0 8
F1 29.0 10 8 - F2 22.0 8
G2 33.5 - 10 8 G2 25.75 8
C2
B3 23.0 8 6 - C2 18.75 6
D3 26.5 8 8 - E3 22.0 8
G1 33.5 - 10 8 G1 25.75 8
C1
B2 23.0 8 6 - C1 18.75 6
B3 23.0 8 6 - C3 18.75 6
E1 33.5 8 8 - F1 22.0 8
B2
C2 23.0 - 6 - D2 18.75 6
B2 23.0 - 6 - B2 18.75 6
B1
C1 23.0 - 6 - D1 18.75 6
B1 23.0 - 6 - B1 18.75 6
