Trane RTHC - Page 37

Installation, Operation and Maintenance 2 - 15
Figure 15Condenser and Evaporator Water Connections -
B1C1D1/B2C2D2
118” (2997mm)
23-1/2”
(597mm)
OUT
IN
Cond
Evap
IN
13-1/2”
11-1/2”
(292mm)
(343mm)
8” (203mm) for 150 psi
8-1/4” (210mm) for 300 psi
4-3/4” (121mm) for 150 psi
5-1/4” (133mm) for 300 psi
Compressor
OUT
IN
126” (3200mm)
64-1/2” (1638 mm)
13-3/8 (340mm)
9-5/8 (245mm)
11-5/8” (295mm) for 150 psi
11-3/4” (298mm) for 300 psi
8-3/8” (213mm) for 150 psi
8-1/2” (216mm) for 300 psi
26-3/8” (670mm) for 150 psi
26-1/4” (667mm) for 300 psi
8-3/8 (213mm) for 150 psi
8-1/2” (216mm) for 300 psi
70-3/4
(1797mm)
Evaporator
2 Pass
6-7/8” (175mm)
2 Pass
OUT
IN
12-7/8” (327mm)
25-1/8” (638mm)
8-7/8” (225mm)
Std. 3 Pass
