Trane RTHC - Page 128

1-27.136-(Back)-(698)
Differential to start set-
point
Differential to stop set-
point
Evap pump off delay
Clear RI timer
SERVICE SETTINGS GROUP
FIELD START-UP GROUP (++--++)
Keypad/display Lock D E
Menu settings password
feature
D E
ICS Address
Power up start delay
time
Design Delta Temp
Setpt
Lvg Wtr Temp Cutout
Setpt
Low Rfgt Cutout Setpt
Condenser Limit Setpt
Max. RI timer
Under/Over Voltage D E
Phase Reversal Protec-
tion
D E
Phase Unbalance Limit D E
Momentary Power Loss
Protection
D E
Soft Load Control D E
Soft Loading Starting
Current Limit
Soft Load Current Limit
Rate
Soft Load Leaving Water
Rate
LWT Control Propor-
tional Gain
LWT Control Integral
Reset TIme
LWT Control Rate TIme
EXV Max Travel Setpt
MENU ITEMS SETTING
Liq. Level Control Pro-
portional Gain
Liq. Level Control Inte-
gral Reset Time
Liq. Level Control Rate
TIme
Local Atmospheric Pres-
sure
SERVICE SETTINGS GROUP
MACHINE CONFIGURATION
GROUP (+-+-+-)
Compressor Frame Size
and Capacity
Nominal Unit Tons
Starter Type
Level 2 Contactor Integ-
rity Test
D E
Rated Load Amps
Motor Heating Constant
Current Overload Setting
#1
Current Overload Setting
#2
Max Acceleration Timer
#1
Max Acceleration Timer
#2
Acceleration Time Out
Action
Shutdown
Transition
EXV Size
External Chilled Water
Setpt Option
Install
Not Install
Ext. Current Limit Option Install
Not Install
High Pressure Cutout
Setting
Line Voltage Sensing
Option
Unit Line Voltage
Ice Building Option Install
Not Install
MENU ITEMS SETTING
Ext. Setpoint Inputs 4-20 ma
2-10 vdc
Tracer Option Install
Not Install
TCI Option Install
Not Install
Print Option Install
Not Install
Relay #1
Relay #2
Relay #3
Rfgt Pres. Output Option
Min Delta Pres. Calib.
Max. Delta Pres. Calib.
MENU ITEMS SETTING
