1-** Load / Motor
Par. No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in-
dex
Type
1-0* General Settings
1-00 Configuration Mode null All set-ups TRUE - Uint8
1-03 Torque Characteristics
[3] Auto Energy Op-
tim. VT
All set-ups TRUE - Uint8
1-2* Motor Data
1-20 Motor Power [kW] ExpressionLimit All set-ups FALSE 1
Uint3
2
1-21 Motor Power [HP] ExpressionLimit All set-ups FALSE -2
Uint3
2
1-22 Motor Voltage ExpressionLimit All set-ups FALSE 0
Uint1
6
1-23 Motor Frequency ExpressionLimit All set-ups FALSE 0
Uint1
6
1-24 Motor Current ExpressionLimit All set-ups FALSE -2
Uint3
2
1-25 Motor Nominal Speed ExpressionLimit All set-ups FALSE 67
Uint1
6
1-28 Motor Rotation Check [0] Off All set-ups FALSE - Uint8
1-29
Automatic Motor Adaptation
(AMA)
[0] Off All set-ups FALSE - Uint8
1-3* Adv. Motor Data
1-30 Stator Resistance (Rs) ExpressionLimit All set-ups FALSE -4
Uint3
2
1-31 Rotor Resistance (Rr) ExpressionLimit All set-ups FALSE -4
Uint3
2
1-35 Main Reactance (Xh) ExpressionLimit All set-ups FALSE -4
Uint3
2
1-36 Iron Loss Resistance (Rfe) ExpressionLimit All set-ups FALSE -3
Uint3
2
1-39 Motor Poles ExpressionLimit All set-ups FALSE 0 Uint8
1-5* Load Indep. Setting
1-50
Motor Magnetisation at Zero
Speed
100 % All set-ups TRUE 0
Uint1
6
1-51
Min Speed Normal Magnetising
[RPM]
ExpressionLimit All set-ups TRUE 67
Uint1
6
1-52
Min Speed Normal Magnetising
[Hz] ExpressionLimit All set-ups TRUE -1
Uint1
6
1-6* Load Depen. Setting
1-60 Low Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-61 High Speed Load Compensation 100 % All set-ups TRUE 0 Int16
1-62 Slip Compensation 0 % All set-ups TRUE 0 Int16
1-63 Slip Compensation Time Constant ExpressionLimit All set-ups TRUE -2
Uint1
6
1-64 Resonance Dampening 100 % All set-ups TRUE 0
Uint1
6
1-65
Resonance Dampening Time Con-
stant
5 ms All set-ups TRUE -3 Uint8
Parameter Lists
TR200 Programming Guide 259
