Trane TR200 Series - Application Functions

Par. No.
#
Parameter description Default value 4-set-up Change
during
opera-
tion
Conver-
sion in-
dex
Type
23-6* Trending
23-60 Trend Variable [0] Power [kW] 2 set-ups TRUE - Uint8
23-61 Continuous Bin Data 0 N/A All set-ups TRUE 0
Uint3
2
23-62 Timed Bin Data 0 N/A All set-ups TRUE 0
Uint3
2
23-63 Timed Period Start ExpressionLimit 2 set-ups TRUE 0
Time-
Of-
Day
23-64 Timed Period Stop ExpressionLimit 2 set-ups TRUE 0
Time-
Of-
Day
23-65 Minimum Bin Value ExpressionLimit 2 set-ups TRUE 0 Uint8
23-66 Reset Continuous Bin Data [0] Do not reset All set-ups TRUE - Uint8
23-67 Reset Timed Bin Data [0] Do not reset All set-ups TRUE - Uint8
23-8* Payback Counter
23-80 Power Reference Factor 100 % 2 set-ups TRUE 0 Uint8
23-81 Energy Cost 1.00 N/A 2 set-ups TRUE -2
Uint3
2
23-82 Investment 0 N/A 2 set-ups TRUE 0
Uint3
2
23-83 Energy Savings 0 kWh All set-ups TRUE 75 Int32
23-84 Cost Savings 0 N/A All set-ups TRUE 0 Int32
24-** Application Functions 2
Par. No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in-
dex
Type
24-0* Fire Mode
24-00 Fire Mode Function [0] Disabled 2 set-ups TRUE - Uint8
24-03 Fire Mode Min Reference ExpressionLimit All set-ups TRUE -3 Int32
24-04 Fire Mode Max Reference ExpressionLimit All set-ups TRUE -3 Int32
24-05 Fire Mode Preset Reference 0.00 % All set-ups TRUE -2 Int16
24-06 Fire Mode Reference Source [0] No function All set-ups TRUE - Uint8
24-09 Fire Mode Alarm Handling
[1] Trip, Critical
Alarms
2 set-ups FALSE - Uint8
24-1* Drive Bypass
24-10 Drive Bypass Function [0] Disabled 2 set-ups TRUE - Uint8
24-11 Drive Bypass Delay Time 0 s 2 set-ups TRUE 0
Uint1
6
Parameter Lists
TR200 Programming Guide 281
