Abbreviations
Alternating current AC
American wire gauge AWG
Ampere/AMP A
Automatic Motor Adaptation AMA
Current limit I
LIM
Degrees Celsius
°C
Direct current DC
Drive Dependent D-TYPE
Electro Magnetic Compatibility EMC
Electronic Thermal Relay ETR
Frequency Converter FC
Gram g
Hertz Hz
Kilohertz kHz
Local Control Panel keypad
Meter m
Millihenry Inductance mH
Milliampere mA
Millisecond ms
Minute min
Trane Drive Utility TDU
Nanofarad nF
Newton Meters Nm
Nominal motor current I
M,N
Nominal motor frequency f
M,N
Nominal motor power P
M,N
Nominal motor voltage U
M,N
Parameter par.
Protective Extra Low Voltage PELV
Printed Circuit Board PCB
Rated Inverter Output Current I
INV
Revolutions Per Minute RPM
Regenerative terminals Regen
Second s
Synchronous Motor Speed n
s
Torque limit T
LIM
Volts V
The maximum output current I
DRIVE,MAX
The rated output current supplied by the frequency converter I
DRIVE,N
Available Literature for TR200
- Operating Instructions provide the necessary information for getting the drive up and running.
- Operating Instructions TR200 High Power
- Design Guide entails all technical information about the drive and customer design and applications.
- Programming Guide (this manual) provides information on how to program and includes complete param-
eter descriptions.
Trane technical literature is available in print from your local Trane Sales Office or online at:
www.trane.com/vfd
Introduction
TR200 Programming Guide 11
