Page #270 background imageLoading...
Page #270 background image
11-** LonWorks
Par. No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in-
dex
Type
11-0* LonWorks ID
11-00 Neuron ID 0 N/A All set-ups TRUE 0
OctSt
r[6]
11-01 Domain 0 N/A All set-ups TRUE 0
OctSt
r[6]
11-02 Subnet ID 0 N/A All set-ups TRUE 0 Uint8
11-03 Node ID 0 N/A All set-ups TRUE 0 Uint8
11-1* LON Functions
11-10 Drive Profile [0] VSD profile All set-ups TRUE - Uint8
11-15 LON Warning Word 0 N/A All set-ups TRUE 0
Uint1
6
11-17 XIF Revision 0 N/A All set-ups TRUE 0
VisSt
r[5]
11-18
LonWorks Revision 0 N/A All set-ups TRUE 0
VisSt
r[5]
11-2* LON Param. Access
11-21 Store Data Values [0] Off All set-ups TRUE - Uint8
13-** Smart Logic Controller
Par. No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in-
dex
Type
13-0* SLC Settings
13-00 SL Controller Mode null 2 set-ups TRUE - Uint8
13-01 Start Event null 2 set-ups TRUE - Uint8
13-02 Stop Event null 2 set-ups TRUE - Uint8
13-03 Reset SLC [0] Do not reset SLC All set-ups TRUE - Uint8
13-1* Comparators
13-10 Comparator Operand null 2 set-ups TRUE - Uint8
13-11 Comparator Operator null 2 set-ups TRUE - Uint8
13-12 Comparator Value ExpressionLimit 2 set-ups TRUE -3 Int32
13-2* Timers
13-20 SL Controller Timer ExpressionLimit 1 set-up TRUE -3 TimD
13-4* Logic Rules
13-40 Logic Rule Boolean 1 null 2 set-ups TRUE - Uint8
13-41 Logic Rule Operator 1 null 2 set-ups TRUE - Uint8
13-42 Logic Rule Boolean 2 null 2 set-ups TRUE - Uint8
13-43 Logic Rule Operator 2 null 2 set-ups TRUE - Uint8
13-44 Logic Rule Boolean 3 null 2 set-ups TRUE - Uint8
13-5* States
13-51 SL Controller Event null 2 set-ups TRUE - Uint8
13-52 SL Controller Action null 2 set-ups TRUE - Uint8
Parameter Lists
