4-** Limits / Warnings
Par. No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in-
dex
Type
4-1* Motor Limits
4-10 Motor Speed Direction [2] Both directions All set-ups FALSE - Uint8
4-11 Motor Speed Low Limit [RPM] ExpressionLimit All set-ups TRUE 67
Uint1
6
4-12 Motor Speed Low Limit [Hz] ExpressionLimit All set-ups TRUE -1
Uint1
6
4-13 Motor Speed High Limit [RPM] ExpressionLimit All set-ups TRUE 67
Uint1
6
4-14 Motor Speed High Limit [Hz] ExpressionLimit All set-ups TRUE -1
Uint1
6
4-16 Torque Limit Motor Mode 110.0 % All set-ups TRUE -1
Uint1
6
4-17 Torque Limit Generator Mode 100.0 % All set-ups TRUE -1
Uint1
6
4-18 Current Limit ExpressionLimit All set-ups TRUE -1
Uint3
2
4-19
Max Output Frequency ExpressionLimit All set-ups FALSE -1
Uint1
6
4-5* Adj. Warnings
4-50 Warning Current Low 0.00 A All set-ups TRUE -2
Uint3
2
4-51 Warning Current High ImaxVLT (P1637) All set-ups TRUE -2
Uint3
2
4-52 Warning Speed Low 0 RPM All set-ups TRUE 67
Uint1
6
4-53 Warning Speed High
outputSpeedHighLi-
mit (P413)
All set-ups TRUE 67
Uint1
6
4-54 Warning Reference Low -999999.999 N/A All set-ups TRUE -3 Int32
4-55 Warning Reference High 999999.999 N/A All set-ups TRUE -3 Int32
4-56 Warning Feedback Low
-999999.999 Proc-
essCtrlUnit All set-ups TRUE -3 Int32
4-57 Warning Feedback High
999999.999 Proc-
essCtrlUnit
All set-ups TRUE -3 Int32
4-58
Missing Motor Phase Function [2] Trip 1000 ms All set-ups TRUE - Uint8
4-6* Speed Bypass
4-60 Bypass Speed From [RPM] ExpressionLimit All set-ups TRUE 67
Uint1
6
4-61 Bypass Speed From [Hz] ExpressionLimit All set-ups TRUE -1
Uint1
6
4-62 Bypass Speed To [RPM] ExpressionLimit All set-ups TRUE 67
Uint1
6
4-63 Bypass Speed To [Hz] ExpressionLimit All set-ups TRUE -1
Uint1
6
4-64 Semi-Auto Bypass Set-up [0] Off All set-ups FALSE - Uint8
Parameter Lists
262 TR200 Programming Guide
