Trane TR200 Series User Manual

6-** Analog In / Out
Par. No.
#
Parameter description Default value 4-set-up Change
during
operation
Conver-
sion in-
dex
Type
6-0* Analog I/O Mode
6-00 Live Zero Timeout Time 10 s All set-ups TRUE 0 Uint8
6-01 Live Zero Timeout Function [0] Off All set-ups TRUE - Uint8
6-02
Fire Mode Live Zero Timeout Func-
tion
[0] Off All set-ups TRUE - Uint8
6-1* Analog Input 53
6-10 Terminal 53 Low Voltage 0.07 V All set-ups TRUE -2 Int16
6-11 Terminal 53 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-12 Terminal 53 Low Current 4.00 mA All set-ups TRUE -5 Int16
6-13 Terminal 53 High Current 20.00 mA All set-ups TRUE -5 Int16
6-14 Terminal 53 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-15 Terminal 53 High Ref./Feedb. Value ExpressionLimit All set-ups TRUE -3 Int32
6-16 Terminal 53 Filter Time Constant 0.001 s All set-ups TRUE -3
Uint1
6
6-17 Terminal 53 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-2* Analog Input 54
6-20 Terminal 54 Low Voltage 0.07 V All set-ups TRUE -2 Int16
6-21 Terminal 54 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-22 Terminal 54 Low Current 4.00 mA All set-ups TRUE -5 Int16
6-23 Terminal 54 High Current 20.00 mA All set-ups TRUE -5 Int16
6-24 Terminal 54 Low Ref./Feedb. Value 0.000 N/A All set-ups TRUE -3 Int32
6-25 Terminal 54 High Ref./Feedb. Value 100.000 N/A All set-ups TRUE -3 Int32
6-26 Terminal 54 Filter Time Constant 0.001 s All set-ups TRUE -3
Uint1
6
6-27
Terminal 54 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-3* Analog Input X30/11
6-30 Terminal X30/11 Low Voltage 0.07 V All set-ups TRUE -2 Int16
6-31 Terminal X30/11 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-34
Term. X30/11 Low Ref./Feedb. Val-
ue 0.000 N/A All set-ups TRUE -3 Int32
6-35
Term. X30/11 High Ref./Feedb. Val-
ue
100.000 N/A All set-ups TRUE -3 Int32
6-36 Term. X30/11 Filter Time Constant 0.001 s All set-ups TRUE -3
Uint1
6
6-37 Term. X30/11 Live Zero [1] Enabled All set-ups TRUE - Uint8
6-4* Analog Input X30/12
6-40 Terminal X30/12 Low Voltage 0.07 V All set-ups TRUE -2 Int16
6-41 Terminal X30/12 High Voltage 10.00 V All set-ups TRUE -2 Int16
6-44
Term. X30/12 Low Ref./Feedb. Val-
ue
0.000 N/A All set-ups TRUE -3 Int32
6-45
Term. X30/12 High Ref./Feedb. Val-
ue 100.000 N/A All set-ups TRUE -3 Int32
6-46 Term. X30/12 Filter Time Constant 0.001 s All set-ups TRUE -3
Uint1
6
6-47 Term. X30/12 Live Zero [1] Enabled All set-ups TRUE - Uint8
Parameter Lists
TR200 Programming Guide 265

Trane TR200 Series Specifications

General

Input Voltage	24 VAC
Frequency Range	50/60 Hz
Communication Protocols	BACnet MS/TP, Modbus RTU
Controller Type	Programmable
Power Range	20 VA
Control Method	PID Control
Enclosure Rating	IP20
Operating Temperature	32°F to 122°F (0°C to 50°C)
Humidity Range	5% to 95% non-condensing
Memory	Non-volatile
