Trane Voyager - General Data - 8½, 10 Ton Standard Efficiency

To Next Page

To Previous Page

Table 11-1 General Data

8½ Ton Downflow and Horizontal Units 10 Ton Downflow and Horizontal Units 10 Ton Downflow and Horizontal Units

✲102C3,C4,CWL YC✲102C3,C4,CWH YC✲120B3,B4,BWH YC✲120C3,C4,CWL YC✲120C3,C4,CWM

Cooling Performance

Gross Cooling Capacity 107,000 125,000 125,000

EER

9.0

9.2

9.0

Nominal CFM / ARI Rated CFM 3,400/3,000 4,000/3,500 4,000/3,500

ARI Net Cooling Capacity 101,000 119,000 117,000

Integrated Part Load Value

9.2

8.90 8.90

System Power (KW) 11.22

12.95

13.00

Heating Performance

Heating Models Low High High Low Medium

Heating Input (Btuh) 135,000 205,000 250,000 135,000 205,000

1st Stage (2 Stage Only) 150,000 175,000 150,000

Heating Output (Btuh) 105,000 166,000 203,000 105,000 166,000

1st Stage (2 Stage Only) 122,000 142,000 122,000

AFUE (%)

81.0 81.0 81.0 81.0 81.0

Steady State Efficiency (%) 81.0 81.0 81.0 81.0 81.0

No. Burners 1 1 1

No. Stages 1 2 2 1 2

Gas Connection Pipe Size (in.) 1/2 1/2 1/2

CompressorCompressor

Compressor

No./Type 2/Climatuff® 2/Climatuff 2/Climatuff

Sound RatingSound Rating

Sound Rating (BELS)

9.2 9.0 9.2

Outdoor Coil -Outdoor Coil -

Outdoor Coil - Type Hi-Performance Hi-Performance Hi-Performance

Tube Size (in.) OD .375 .375 .375

Face Area (sq ft) 16.03 14.58 18.67

Rows/FPI 2/16 2/16 2/16

Indoor Coil Indoor Coil

Indoor Coil - Type Hi-Performance Hi-Performance Hi-Performance

Tube Size (in.) .375 .375 .375

Face Area (sq ft) 10.50 11.13 10.50

Rows/FPI 2/15 2/15 3/15

Refrigerant Control Short Orifice Short Orifice Short Orifice

Drain Connection No./Size (in.) 1/0.75 PVC 1/1.00 NPT 1/0.75 PVC

Outdoor FanOutdoor Fan

Outdoor Fan - Type Propeller Propeller Propeller

No. Used/Diameter (in.) 1/26 1/26 1/26

Drive Type/No. Speeds Direct/1 Direct/1 Direct/1

CFM 7,000 7,200 7,700

No. Motors/HP 1/1.0 1/1.0 1/1.0

Motor RPM 1,125 1125 1125

Indoor FanIndoor Fan

Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal

No. Used/Diameter (in.) 1/15 X 11 1/15 X 11 1/15 X 11

Drive Type/No. Speeds Belt/1 Belt/1 Belt/1

No. Motors 1 1 1

Motor HP (Standard/Oversized) 2.0/3.0 2.0/3.0 3.0/5.0

Motor RPM (Standard/Oversized) 1740/1740 1740/1740 1740/3450

Motor Frame Size (Standard/Oversized) 145T/145T 145T/145T 145T/145T

FiltersFilters

Filters - Type/Furnished Throwaway/Yes Throwaway/Yes Throwaway/Yes

(No.) Size Recommended

Downflow (2) 16 X 20 X 2 (2) 20 X 20 X 2 (3) 20 X 20 X 2 (3) 16 X 20 X 2 (2) 16 X 20 X 2 (2) 20 X 20 X 2

Horizontal (2) 16 X 25 X 2 (2) 20 X 25 X 2 (4) 20 X 25 X 2 (2) 16 X 25 X 2 (2) 20 X 25 X 2

Refrigerant Charge Refrigerant Charge

Refrigerant Charge (Lbs of R-22)

7.1/Circuit 6.9/7.2/Circuit 8.5/Circuit

NOTES

1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat.

ARI capacity is net and includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Rated in accordance with ARI Standard 210/240 or 360.

2. EER is rated at ARI conditions and in accordance with ARI Standards 210/240 or 360.

3. Integrated Part Load Value is based on ARI Standard 210/240, or 360. Units are rated at 80° F ambient, 80° F entering dry bulb, and 67° F entering wet bulb at ARI rated cfm.

4. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards.

Ratings shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.

5. AFUE is rated in accordance with DOE test procedures.

6. Sound Rating is rated in accordance with ARI Standard 270 or 370..

7. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.

8. Horizontal models have 9.1 EER, 11.10 system power KW, and 9.3 IPVL.

9. Horizontal models have 9.0 EER and 13.22 system power KW.

General 8½, 10 Ton

Data

Standard Efficiency

✲Indicates both downflow and horizontal units.
