57
✲Indicates both downflow and horizontal units.
Table 57-1 Electrical Characteristics — Compressor Motor And Condenser Motor — 60 Cycle — Std. Efficiency
Compressor Motor Compressor Motor
Compressor Motor Compressor Motor
Compressor Motor
Condenser Fan Motors Condenser Fan Motors
Condenser Fan Motors Condenser Fan Motors
Condenser Fan Motors
Unit
Amps
1
Amps
1
Tons Model No. No. Volts Phase HP
3
RPM RLA LRA No. Phase HP FLA LRA
YCD036C1 1 208-230 1 3.00 3450 18.0 92 1 1 .25 2.0 5.3
3 YCD036C3 1 208-230 3 3.00 3450 11.2 101 1 1 .25 2.0 5.3
YCD036C4 1 460 3 3.00 3450 5.5 51 1 1 .25 .9 2.1
YC✲048C1 1 208-230 1 4.00 3450 24.0 119 1 1 .33 2.1 4.8
YC
✲048C3 1 208-230 3 4.00 3450 14.8 101 1 1 .33 2.1 4.8
4
YC
✲048C4 1 460 3 4.00 3450 7.1 51 1 1 .33 1.0 2.6
YC
✲048CW 1 575 3 4.00 3450 5.5 41 1 1 .33 0.9 2.1
YC✲060C1 1 208-230 1 5.00 3450 28.8 142 1 1 .50 5.2 6.5
YC
✲060C3 1 208-230 3 5.00 3450 18.6 118 1 1 .40 2.7 7.8
5
YC
✲060C4 1 460 3 5.00 3450 10.0 71 1 1 .40 1.3 3.2
YC
✲060CW 1 575 3 5.00 3450 6.7 43 1 1 .40 1.1 2.4
YC✲075C3 1 208-230 3 6.25 3450 21.8 124 1 1 .50 3.4 10.8
6¼ YC
✲075C4 1 460 3 6.25 3450 9.7 64 1 1 .50 2.4 5.4
YC
✲075CW 1 575 3 6.25 3450 7.8 51 1 1 .50 1.8 4.1
YC✲090C3 1 208-230 3 7.50 3450 27.0 164 1 1 .50 3.4 10.8
YC
✲090C4 1 460 3 7.50 3450 12.2 79 1 1 .50 2.4 5.4
YC
✲090CW 1 575 3 7.50 3450 9.8 63 1 1 .50 1.8 4.1
7½
YC
✲090D3
2
2 208-230 3 4.00/3.50 3450 14.4/14.4 101 1 1 .50 3.4 10.8
YC
✲090D4
2
2 460 3 4.00/3.50 3450 7.1/6.3 51 1 1 .50 2.4 5.4
YC
✲090DW
2
2 575 3 4.00/3.50 3450 5.4/4.8 41 1 1 .50 1.8 4.1
YC✲102C3 2 208-230 3 4.30 3450 16.0 118 1 1 1.00 5.5 18.3
8½ YC
✲102C4 2 460 3 4.30 3450 10.0 71 1 1 1.00 2.9 9.3
YC
✲102CW 2 575 3 4.30 3450 5.9 43 1 1 1.00 2.0 5.7
YC✲120B3, C3 2 208-230 3 5.00
4
3450 19.0
5
118 1 1 1.00 5.5 18.3
10 YC
✲120B4, C4 2 460 3 5.00
4
3450 10.0 71 1 1 1.00 2.9 9.3
YC
✲120BW, CW 2 575 3 5.00
4
3450 6.9 43 1 1 1.00 2.0 5.7
YC✲150C3 2 208-230 3 6.25 3450 24.3 124 1 1 1.00 5.3 18.3
12½ YC
✲150C4 2 460 3 6.25 3450 10.6 64 1 1 1.00 2.9 9.3
YC
✲150CW 2 575 3 6.25 3450 8.4 51 1 1 1.00 2.0 5.7
YC✲180B3 2 208-230 3 7.50 3450 28.7 156 2 1 .50 3.2 8.8
15 YC
✲180B4 2 460 3 7.50 3450 12.7 79 2 1 .50 1.6 3.8
YC
✲180BW 2 575 3 7.50 3450 10.2 63 2 1 .50 1.3 3.2
YC✲210C3 2 208-230 3 8.30 3450 31.9 179 2 1 1.00 5.5 18.3
17½ YC
✲210C4 2 460 3 8.30 3450 14.5 90 2 1 1.00 2.9 9.3
YC
✲210CW 2 575 3 8.30 3450 11.6 72 2 1 1.00 2.0 5.7
YC✲240B3 2 208-230 3 9.30 3450 42.1 247 2 1 1.00 5.5 18.3
20 YC
✲240B4 2 460 3 9.30 3450 17.4 95 2 1 1.00 2.9 9.3
YC
✲240BW 2 575 3 9.30 3450 13.9 76 2 1 1.00 2.0 5.7
YC✲300B3 2 208-230 3 10.00 3450 42.8 247 2 1 1.00 5.5 18.3
25 YC
✲300B4 2 460 3 10.00 3450 17.7 95 2 1 1.00 2.9 9.3
YC
✲300BW 2 575 3 10.00 3450 14.2 76 2 1 1.00 2.0 5.7
NOTES:
1. Amp draw for each motor; multiply value by number of motors to determine total amps.
2. Compressor one 4 HP/Compressor two 3.5 HP
3. HP for each compressor.
4. YC
✲120C3,C4,CW compressor HP is 5.00/4.30.
5. YC
✲120C3 RLA for compressor #2 is 16.0.
Electrical
Data
Standard
Efficiency
