20
Table 20-1 General Data
17½ Ton 20 Ton 25 Ton Units
Downflow and Horizontal Units Downflow and Horizontal Units Downflow and Horizontal Units
YC
✲211C3,C4,CW YC✲241C3,C4,CW YC✲301C3,C4,CW
Cooling Performance
1
Gross Cooling Capacity 220,000 268,000 300,000
EER
2
11.0 10.6 10.4
Nominal CFM / ARI Rated CFM 7,000 / 6,200 8,000 / 7,000 10,000/8,750
ARI Net Cooling Capacity 208,000 250,000 278,000
Integrated Part Load Value
3
12.0 11.2 11.0
System Power (KW) 18.91 23.58 26.73
Heating Performance
4
Heating Models Low High Low High Low High
Heating Input (Btuh) 250,000 350,000 250,000 400,000 250,000 400,000
1st Stage 175,000 250,000 175,000 300,000 175,000 300,000
Heating Output (Btuh) 203,000 284,000 203,000 324,000 203,000 324,000
1st Stage 142,000 203,000 142,000 243,000 142,000 243,000
AFUE%
5
(Downflow/Horizontal) 80.2 / 81.0 79.3 / 79.7 80.2 / 81.0 79.8 / 79.7 80.2/81.0 79.8/79.7
Steady State Efficiency (%)
5
81.0 81.0 81.0 81.0 81.0 81.0
No. Burners 1 1 1 1 1 1
No. Stages 2 2 2 2 2 2
Gas Connection Pipe Size (in.) 1/2 3/4 1/2 3/4 1/2 3/4
Compressor
No./Type 2/Trane 3-D® Scroll/Copeland Scroll 2/Trane 3-D Scroll 2/Trane 3-D Scroll
Sound Rating (BELS)
6
9.4 9.4 9.4
Outdoor Coil - Type High-Performance High-Performance High Performance
Tube Size (in.) OD 0.375 0.375 0.375
Face Area (sq ft) 35.30 35.30 35.30
Rows/FPI 3/16 3/16 3/16
Indoor Coil - Type High-Performance High-Performance High Performance
Tube Size (in.) 0.375 0.375 0.375
Face Area (sq ft) 26.00 26.00 26.00
Rows/FPI 4/15 4/15 4/15
Refrigerant Control Short Orifice Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/1.0 NPT 1/1.0 NPT 1/1.0 NPT
Outdoor Fan - Type Propeller Propeller Propeller
No. Used/Diameter (in.) 2/26 2/26 2/26
Drive Type/No. Speeds Direct/1 Direct/1 Direct/1
CFM 12,800 13,700 13,700
No. Motors/HP 2/1.0 2/1.0 2/1.0
Motor RPM 1125 1125 1125
Indoor Fan - Type FC Centrifugal FC Centrifugal FC Centrifugal
No. Used/Diameter (in.) 1/18 x 18 1/18 x 18 1/18x18
Drive Type/No. Speeds BELT/1 BELT/1 BELT/1
No. Motors 1 1 1
Motor HP (Standard/Oversized) 5.0/7.5 5.0/7.5 7.5
Motor RPM (Standard/Oversized) 3450/3470 3450/3470 3470
Motor Frame Size (Standard/Oversized) 145T/184T 145T/184T 184T
Filters - Type Throwaway Throwaway Throwaway
Furnished? Yes Yes Yes
(No.) Size Recommended (4)20 X 20 X 2/(4)20 X 25 X 2
8
(4)20 X 20 X 2/(4)20 X 25 X 2
8
(4)20 X 20 X 2/(4)20 X 25 X 2
8
Refrigerant Charge (Lbs of R-22)
7
/Circuit 25.7/12.5 22.0/22.0 24.5/24.5
NOTES:
1. Cooling Performance is rated at 95F ambient, 80F entering dry bulb, 67F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net
and includes the effect of fan motor heat. Rated in accordance with ARI Standard 210/240 or 360
2. EER is rated at ARI conditions and in accordance with DOE test procedures.
3. Integrated Part Load Value is based On ARI Standard 210/240 or 360. Units are rated at 80F ambient, 80F entering dry bulb, and 67F entering wet bulb at ARI rated cfm.
4. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards
Ratings shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
5. AFUE and Steady State Efficiency is rated in accordance with DOE test procedures.
6. Sound Rating is rated in accordance with ARI Standard 270 or 370.
7. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
8. Horizontal Models have 8 -20 x 25 x 2 filters.
✲Indicates both downflow and horizontal units.
General 17½
,,
,,
, 20, 25 Ton
Data
High Efficiency
