External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5 HP Standard Motor &
Field Supplied Low Static Drive (1) 5 HP Standard Motor & Drive
6400 511 1.56 538 1.72 564 1.99 590 2.16 615 2.31 639 2.47 663 2.65 688 2.84 711 3.04 735 3.23 758 3.4 781 3.64 804 3.85
7200 555 2.25 587 2.46 614 2.67 640 2.88 663 3.06 685 3.23 706 3.41 728 3.60 749 3.80 771 4.01 792 4.24 813 4.46 834 4.68
8000 609 3.03 639 3.26 665 3.50 690 3.73 712 3.96 733 4.16 753 4.35 772 4.55 792 4.75 811 4.96 830 5.18 850 5.42 869 5.66
8800 664 3.98 692 4.23 717 4.49 740 4.75 762 5.01 782 5.25 801 5.48 820 5.69 838 5.90 855 6.12 873 6.34 890 6.58 908 6.82
9600 719 5.11 745 5.38 770 5.66 792 5.94 813 6.23 832 6.51 851 6.78 869 7.03 886 7.27 902 7.50 919 7.73 935 7.97 951 8.21
(2) 7.5 HP Oversize Motor & Drive
5 HP Standard Motor & High Static Drive Accessory
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5 HP Standard Motor & High Static Drive Accessory
6400 827 4.07 848 4.29 869 4.51 890 4.73 910 4.97 929 5.21 949 5.45
7200 854 4.90 875 5.13 895 5.37 916 5.62 936 5.86 955 6.11 973 6.35
8000 888 5.91 907 6.16 925 6.40 944 6.65 962 6.90 981 7.16 1000 7.44
8800 925 7.08 943 7.34 961 7.61 978 7.88 995 8.16 — — — —
9600 967 8.46 983 8.73 999 9.00 — — — — — — — —
7.5 HP Oversize Motor & Drive
Performance
Data
17½
, ,
, ,
, 20 Ton
Standard Efficiency
✲Indicates both downflow and horizontal units.
Table 44-1 Evaporator Fan Performance 17 1/2 Ton YC
✱✱
✱✱
✱210C
Table 44-2 (Continued)
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged conditions.
Using the full horsepower range of our fan motors as shown in our tabular data will not result in
nuisance tripping or premature motor failure. Our product’s warranty will not be affected.
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standatd Motor and High Static Drive Accessory/Fan Speed (RPM),
reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Fan motor heat (MBH) = 3.15 x Fan Bhp.
Data includes pressure Drop Due to West Coils and Filters.
1. Field Supplied Fan Sheave BK190 Required.
Field Supplied Belt may be necessary.
2. 7.5 HP Oversize Motor with Field Supplied Motor Sheave 1VP50 Required.
Field Supplied Belt may be necessary.
Table 44-2 Evaporator Fan Performance 20 Ton YC
✱✱
✱✱
✱240B
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5 HP Standard Motor with Low Static Drive Accessory 5 HP Standard Motor & Drive
5600 — — 706 2.20 730 2.32 754 2.44 778 2.57 802 2.71 825 2.85 848 3.00 870 3.15 893 3.30 916 3.46 939 3.63 962 3.80
6300 758 2.92 783 3.07 804 3.20 826 3.33 847 3.46 868 3.61 890 3.76 911 3.92 931 4.09 951 4.25 971 4.42 991 4.59 1012 4.76
7000 835 3.96 861 4.14 881 4.28 899 4.43 919 4.57 938 4.72 957 4.88 976 5.05 995 5.23 1014 5.41 1033 5.58 1051 5.77 1069 5.95
7700 913 5.21 938 5.43 957 5.60 975 5.76 992 5.92 1010 6.08 1027 6.24 1045 6.41 1062 6.59 1079 6.78 1097 6.98 1114 7.17 1131 7.37
8400 991 6.72 1016 6.98 1035 7.17 1052 7.35 1067 7.52 1083 7.69 1099 7.87 1115 8.05 1131 8.23 1147 8.42 1163 8.62 — — — —
7.5 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
5 HP Standard Motor & Drive
5600 984 3.99 1006 4.17 1029 4.36 1051 4.54 1073 4.73 1095 4.92 1117 5.12
6300 1032 4.94 1053 5.13 1073 5.32 1093 5.53 1113 5.73 1133 5.94 1152 6.15
7000 1087 6.14 1105 6.33 1123 6.52 1142 6.72 1160 6.92 1178 7.13 1197 7.36
7700 1147 7.57 1164 7.77 1180 7.97 1196 8.18 1213 8.39 1230 8.60 — —
8400 — — — — — — — — — — — — — —
7.5 HP Oversize Motor & Drive
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor and Low Static Drive, reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Fan motor heat (MBH) = 3.15 x Fan Bhp.
Data includes pressure Drop Due to West Coils and Filters.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged conditions.
Using the full horsepower range of our fan motors as shown in our tabular data will not result in
nuisance tripping or premature motor failure. Our product’s warranty will not be affected.
