39
Table 39-1 Evaporator Fan Performance 6¼ And 7½ Ton YC
✱✱
✱✱
✱075C, YC
✱✱
✱✱
✱090C
External Static Pressure (Inches of Water)
Unit .10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.25 1.50
Tons Model No. CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1 HP Standard Motor & Field
Supplied Low Static Drive
1
1 HP Standard Motor & Sheaves
2000 659 .46 715 .53 771 .60 822 .67 873 .74 924 .81 975 .88 1026 .96 1078 1.04 ——————
2250 728 .63 778 .71 828 .79 877 .87 922 .95 967 1.03 1013 1.11 1058 1.19 1103 1.27 1148 1.35 ————
YCH075C-H 2500 798 .84 843 .93 888 1.02 934 1.11 977 1.20 1018 1.28 1058 1.37 1099 1.46 1140 1.55 1181 1.64 ————
2750 869 1.10 910 1.20 951 1.29 993 1.39 1033 1.49 1073 1.58 1110 1.68 1147 1.78 1183 1.87 1221 1.97 ————
3000 940 1.41 979 1.51 1016 1.62 1054 1.72 1092 1.83 1129 1.94 1165 2.04 1200 2.15 1234 2.25 1267 2.36 ————
2 HP Oversized Motor & Sheaves
6¼
1 HP Standard Motor & Field
Supplied Low Static Drive
1
1 HP Standard Motor & Sheaves
2000 597 .39 646 .44 692 .50 739 .55 782 .60 825 .66 868 .71 907 .76 947 .81 986 .86 1082 .98 — —
YCD075C-L,H 2250 659 .53 705 .59 745 .65 787 .72 829 .78 867 .84 905 .90 944 .96 982 1.02 1017 1.08 1104 1.22 1190 1.35
YCH075C-L 2500 723 .71 765 .78 802 .85 839 .92 877 .99 914 1.05 950 1.12 984 1.19 1019 1.26 1054 1.32 1134 1.49 1213 1.64
2750 789 .93 826 1.01 862 1.08 895 1.15 928 1.23 963 1.31 997 1.38 1030 1.45 1061 1.53 1092 1.60 1171 1.79 1244 1.97
3000 855 1.19 887 1.27 922 1.36 953 1.44 983 1.52 1014 1.60 1046 1.68 1078 1.76 1108 1.85 1137 1.93 1209 2.13 — —
2 HP Oversized Motor & Sheaves
2 HP Standard Motor & Field
Supplied Low Static Drive
2
2HP Standard Motor & Sheaves
2400 795 .75 845 .81 891 .87 938 .94 983 .99 1025 1.03 1065 1.08 1107 1.12 1153 1.17 1200 1.21 ————
2700 884 1.05 926 1.12 970 1.19 1010 1.26 1052 1.33 1093 1.39 1131 1.44 1167 1.49 1203 1.54 1241 1.59 ————
YCH090C-H 3000 974 1.42 1010 1.50 1051 1.58 1089 1.65 1125 1.73 1162 1.80 1200 1.88 1235 1.94 1268 1.99 ——————
3300 1064 1.87 1097 1.95 1133 2.04 1170 2.13 1203 2.21 1235 2.29 1270 2.38 ——————————
3600 1154 2.41 1185 2.50 ————— ———————————————
7½
1 HP Standard Motor & Sheaves
2400 721 .62 760 .66 801 .71 840 .76 879 .80 916 .85 952 .89 988 .92 1025 .96 1058 .99 1142 1.05 1226 1.10
YCD090C-L,H 2700 802 .86 836 .92 872 .97 908 1.03 943 1.08 977 1.13 1011 1.17 1043 1.22 1075 1.27 1108 1.31 1186 1.40 1259 1.47
YCH090C-L 3000 884 1.17 915 1.23 946 1.29 979 1.35 1011 1.41 1042 1.47 1073 1.52 1104 1.57 1134 1.63 1163 1.68 1236 1.80 — —
3300 966 1.54 994 1.60 1022 1.67 1051 1.73 1081 1.80 1111 1.87 1139 1.93 1167 1.99 1195 2.05 1223 2.11 ————
3600 1048 1.98 1075 2.06 1101 2.12 1126 2.20 1153 2.27 1181 2.34 1208 2.42 1234 2.49 1260 2.55 ——————
2 HP Oversized Motor & Sheaves
Table 39-2 Evaporator Fan Performance 7½ Ton Dual Compressor YC
✱✱
✱✱
✱090D
External Static Pressure (Inches of Water)
Unit .10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.25 1.50
Tons Model No. CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor & Field Supplied
Low Static Drive
2
2 HP Standard Motor & Sheaves
2400 769 0.72 817 0.78 864 0.84 911 0.90 957 0.96 1000 1.01 1041 1.05 1082 1.10 1125 1.14 1169 1.18 ————
2700 854 1.00 897 1.07 939 1.14 980 1.21 1022 1.28 1064 1.34 1103 1.40 1140 1.45 1177 1.50 1213 1.55 ————
YCH090D-H 3000 940 1.35 978 1.43 1016 1.51 1054 1.58 1092 1.66 1129 1.74 1167 1.81 1204 1.88 1238 1.94 1271 2.00 ————
3300 1027 1.77 1062 1.86 1096 1.95 1131 2.04 1165 2.12 1199 2.20 1233 2.29 1268 2.37 ———————
3600 1115 2.28 1146 2.38 1178 2.48 — — — ———————————————
1 HP Standard Motor
2400 698 0.59 739 0.64 779 0.69 819 0.74 857 0.78 895 0.82 931 0.86 967 0.90 1004 0.94 1039 0.97 1121 1.04 1203 1.09
YCD090D-L,H 2700 775 0.82 813 0.88 848 0.93 884 0.99 919 1.04 953 1.09 987 1.14 1020 1.19 1052 1.23 1084 1.28 1164 1.38 1237 1.45
YCH090D-L 3000 853 1.11 888 1.18 920 1.24 952 1.30 984 1.36 1016 1.42 1047 1.47 1077 1.53 1108 1.58 1137 1.63 1209 1.76 — —
3300 932 1.46 963 1.53 994 1.60 1023 1.67 1052 1.74 1081 1.80 1110 1.87 1138 1.93 1166 1.99 1194 2.05 1261 2.20 — —
3600 1011 1.88 1040 1.96 1069 2.04 1096 2.11 1122 2.18 1148 2.26 1176 2.33 1203 2.40 1229 2.47 1254 2.54 ————
2 HP Oversize Motor & Sheaves
Data includes pressure drop due to filters and wet coil.
Fan motor heat (MBH) = 3.53 x Fan Bhp.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions.
Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature motor failure. Our product’s warranty will not be affected.
NOTES:
1. Field supplied Browning fan sheave AL74 and Belt A48 required.
2. Field supplied Browning motor sheave IVL34 and Belt A48 required.
Performance 6¼
,,
,,
, 7½ Ton
Data
