Trane Voyager - Performance Data - 12½, 15 Ton High Efficiency

50
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Field
Supplied Low Static Drive (1)
3 HP Standard Motor & Drive
4000 — — — — 520 1.01 550 1.13 580 1.25 610 1.38 638 1.51 666 1.65 693 1.80 720 1.95 746 2.10 771 2.26 795 2.41
4500 502 1.10 533 1.21 562 1.34 590 1.47 617 1.60 644 1.73 671 1.88 696 2.03 721 2.18 746 2.33 770 2.49 794 2.66 818 2.83
5000 551 1.47 579 1.61 606 1.74 632 1.87 657 2.02 682 2.17 706 2.31 730 2.46 754 2.63 777 2.80 799 2.96 821 3.13 843 3.31
5500 600 1.92 627 2.08 651 2.22 675 2.37 699 2.52 722 2.68 744 2.85 766 3.00 788 3.16 810 3.34 831 3.52 852 3.70 873 3.89
6000 649 2.46 675 2.64 698 2.79 720 2.94 742 3.11 764 3.28 785 3.46 805 3.64 825 3.81 845 3.98 865 4.15 885 4.35 905 4.55
3 HP Standard Motor & Drive
5 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard
Motor & Drive
3 HP Standard Motor & High
Static Drive Assembly
4000 819 2.57 842 2.72 864 2.89 886 3.05 908 3.22 929 3.40 951 3.58
4500 841 3.01 863 3.18 885 3.35 906 3.53 927 3.70 947 3.88 967 4.06
5000 865 3.49 887 3.68 908 3.87 929 4.07 949 4.26 969 4.45 988 4.64
5500 893 4.07 913 4.26 933 4.46 953 4.66 972 4.87 992 5.08 1011 5.29
6000 924 4.75 943 4.95 962 5.15 980 5.35 999 5.56 — — — —
5 HP Oversize Motor & Drive
Performance 12½, 15 Ton
Data
High Efficiency
✲Indicates both downflow and horizontal units.
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor & High Static Drive Accessory/Fan Speed (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave BK115 required.
Field Supplied Belt may be necessary.
Table 50-1 Evaporator Fan Performance 12½ Ton YCH151C
Table 50-1 (Continued)
Table 50-2 Evaporator Fan Performance 15 Ton YC
✲✲
✲✲
✲181C
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Field Supplied
Low Static Drive (1)
4800 414 0.81 450 0.94 483 1.06 515 1.20 548 1.35 578 1.50 609 1.66 640 1.83 668 2.00 694 2.18 719 2.36 744 2.55 769 2.75
5400 456 1.11 490 1.26 520 1.39 549 1.54 578 1.70 607 1.87 635 2.03 662 2.21 689 2.39 716 2.58 742 2.77 766 2.97 789 3.17
6000 499 1.48 531 1.65 559 1.81 585 1.96 611 2.12 638 2.29 664 2.48 689 2.67 714 2.85 738 3.05 763 3.25 788 3.46 811 3.68
6600 542 1.92 572 2.12 599 2.3 624 2.46 648 2.63 671 2.81 695 3.00 719 3.20 743 3.41 765 3.62 788 3.82 810 4.03 832 4.26
7200 586 2.45 614 2.67 640 2.88 663 3.06 686 3.24 708 3.42 729 3.61 751 3.82 773 4.04 795 4.26 816 4.49 837 4.71 857 4.94
3 HP Standard Motor & Sheave 5 HP Oversize Motor & Drive
3 HP Standard Motor &
High Static Drive Accessory
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Field
Supplied High Static Drive
4800 792 2.95 815 3.14 838 3.34 859 3.54 880 3.73 901 3.93 921 4.13
5400 811 3.38 833 3.59 855 3.81 876 4.03 897 4.26 917 4.48 937 4.70
6000 833 3.89 855 4.11 875 4.33 896 4.56 916 4.80 935 5.04 955 5.28
6600 855 4.49 877 4.72 898 4.96 918 5.20 937 5.43 956 5.67 — —
7200 878 5.17 898 5.41 919 5.66 — — — — — — — —
5 HP Oversize Motor & Drive
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor and High Static Drive (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave BK120 required. Field Supplied Belt
May be necessary.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically
designed and tested to operate reliably and continuously at all cataloged conditions. Using the full
horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping
or premature motor failure. Our product’s warranty will not be affected.
Table 50-2 (Continued)
