External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & (2)
Field Supplied Low Static Drive (1) 3 HP Standard Motor & Drive
4000 607 1.21 643 1.35 677 1.49 708 1.64 738 1.79 768 1.95 798 2.12 828 2.29 857 2.47 886 2.66 913 2.85 940 3.03 966 3.22
4500 674 1.68 707 1.84 738 1.99 767 2.16 794 2.32 821 2.49 848 2.67 875 2.85 902 3.04 928 3.24 954 3.44 980 3.65 1005 3.86
5000 742 2.27 772 2.44 801 2.61 828 2.79 854 2.97 878 3.15 903 3.34 926 3.53 951 3.73 975 3.94 999 4.15 1023 4.37 1047 4.59
5500 811 2.98 838 3.17 864 3.36 890 3.55 915 3.74 938 3.94 960 4.14 983 4.34 1004 4.55 1026 4.77 1048 4.99 1071 5.22 1092 5.45
6000 880 3.82 905 4.03 929 4.24 953 4.45 977 4.66 999 4.87 1020 5.08 1041 5.30 1061 5.52 1081 5.75 — — — — — —
5 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
(2) 5 HP Oversize Motor & Drive
4000 991 3.41 1015 3.61 1039 3.81 1063 4.00 1085 4.21 1108 4.41 1130 4.62
4500 1029 4.07 1053 4.28 1076 4.49 1099 4.71 1121 4.92 1143 5.14 1164 5.36
5000 1070 4.82 1093 5.05 1115 5.28 1137 5.51 1159 5.75 — — (3)
5500 1114 5.69 — — — — — — (3) — — — —
6000 — — — — — — — — — — — — — —
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor &
Field Supplied Low Static Drive (1)
3 HP Standard Motor with Standard Drive
4800 — — 584 1.22 613 1.33 647 1.49 676 1.59 704 1.71 732 1.84 759 1.98 785 2.13 811 2.26 836 2.38 862 2.51 887 2.64
5200 591 1.41 623 1.53 649 1.61 679 1.78 709 1.93 736 2.04 762 2.17 788 2.31 831 2.46 837 2.62 861 2.76 885 2..90 908 3.04
5600 633 1.73 661 1.89 688 1.96 713 2.09 742 2.29 769 2.43 793 2.55 817 2.69 842 2.84 865 3.00 888 3.17 910 3.33 932 3.49
6000 674 2.10 699 2.28 727 2.37 749 2.48 775 2.66 802 2.86 826 3.00 849 3.13 872 3.28 894 3.44 916 3.61 938 3.78 959 3.96
6400 716 2.52 739 2.73 766 2.85 788 2.94 809 3.08 835 3.30 860 3.50 882 3.65 903 3.79 925 3.94 946 4.10 967 4.28 987 4.47
6800 758 3.00 779 3.22 804 3.38 827 3.47 847 3.58 868 3.77 892 4.01 915 4.21 936 4.37 957 4.52 977 4.67 997 4.84 1017 5.03
7200 800 3.54 820 3.76 842 3.96 866 4.07 885 4.17 904 4.32 925 4.54 948 4.81 970 5.01 990 5.17 1009 5.33 1028 5.49 1047 5.67
5 HP Oversize Motor & Drive
3 HP Standard Motor & High Static Drive Accessory
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & 5 HP Oversize
High Static Drive Accessory Motor & Drive
4800 912 2.77 937 2.90 962 3.04 987 3.19 1011 3.34 1034 3.49 1057 3.65
5200 932 3.18 955 3.31 978 3.46 1002 3.60 1025 3.75 1047 3.90 1070 4.06
5600 954 3.64 976 3.79 998 3.93 1020 4.08 1042 4.23 1063 4.38 1085 4.54
6000 980 4.13 1001 4.31 1021 4.46 1042 4.62 1062 4.78 1082 4.93 1103 5.09
6400 1007 4.66 1027 4.85 1047 5.03 1066 5.21 1085 5.38 1104 5.55 — —
6800 1036 5.22 1055 5.42 1074 5.62 — — — — — — — —
5 HP Oversize Motor &
Field Supplied High Static Drive (2)
Performance
Data
12½
, ,
, ,
, 15 Ton
Standard Efficiency
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
Table 43-1 (Continued)
Table 43-2 (Continued)
Trane’s factory supplied motors, in commercial equipment, are definite
purpose motors, specifically designed and tested to operate reliably and
continuously at all cataloged conditions. Using the full horsepower range of
our fan motors as shown in our tabular data will not result in nuisance tripping
or premature motor failure. Our product’s warranty will not be affected.
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Fan motor heat (MBH) = 3.15 x Fan Bhp.
Data includes pressure Drop Due to Wet Coils and Filters.
1. Field Supplied Fan Sheave BK105 Required. Field Supplied Belt may be necessary.
2. 5 HP Oversize Motor with Field Supplied Motor Sheave 1VP50 Required.
Field Supplied Belt may be necessary.
Table 43-2 Evaporator Fan Performance 15 Ton YC
✲✲
✲✲
✲180B
Table 43-1 Evaporator Fan Performance 12 1/2 Ton YCH150C
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor & High Static Drive Accessory Fan Speed (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
1. Field Supplied Fan Sheave BK90 Required. Field Supplied Belt may be Necessary.
2. 3 HP Standard Motor with Field Supplied Motor Sheave IVP44 Required. Field Supplied Belt may be
Necessary.
3. 5 HP Oversize Motor with Field Supplied Motor Sheave 1VP50 Required.
Field Supplied Belt may be Necessary.
