Trane Voyager - Performance Data 10, 12½ Ton High Efficiency

49
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & Field
Supplied Low Static Drive (1)
3 HP Standard Motor & Drive
3 HP Standard
Motor & High Static
Drive Accy
4000 — — 497 0.75 551 0.92 598 1.08 641 1.23 680 1.38 716 1.53 750 1.67 782 1.82 812 1.96 841 2.09 869 2.23 896 2.36
4500 — — 531 0.96 583 1.16 629 1.34 671 1.52 709 1.70 745 1.87 778 2.03 810 2.20 840 2.36 869 2.52 896 2.68 923 2.84
5000 506 0.98 565 1.21 616 1.43 661 1.65 701 1.85 739 2.05 774 2.25 807 2.44 838 2.63 868 2.81 897 2.99 924 3.17 950 3.35
5500 544 1.24 600 1.51 649 1.76 693 2.00 733 2.23 770 2.45 804 2.67 837 2.89 868 3.10 897 3.31 925 3.52 952 3.72 978 3.92
6000 582 1.55 636 1.84 684 2.12 726 2.39 765 2.65 801 2.90 835 3.15 867 3.39 898 3.63 927 3.86 955 4.09 981 4.32 1007 4.54
3 HP Standard Motor & Drive 5 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor & High Static Drive Accessory
4000
922 2.50 947 2.63 971 2.76 994 2.89 1016 3.04 1037 3.19 1059 3.35
4500
948 2.99 973 3.14 997 3.30 1020 3.45 1043 3.60 1065 3.75 1087 3.89
5000
976 3.53 1000 3.71 1024 3.88 1047 4.05 1070 4.22 1092 4.39 1113 4.56
5500
1004 4.12 1028 4.32 1052 4.51 1075 4.71 1097 4.90 1119 5.09 1140 5.28
6000
1032 4.77 1056 4.99 1080 5.21 1103 5.42 1125 5.64
— — — —
5 HP Oversize Motor & Drive
Performance 10, 12½ Ton
Data
High Efficiency
✱Indicates both downflow and horizontal units.
Table 49-1 Evaporator Fan Performance 10 Ton YCH121C
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor & High Static Drive Accessory/Fan Speed (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave BK115 required. Field Supplied Belt
may be necessary.
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor & Field
Supplied Low Static Drive (1)
2 HP Standard Motor & Drive
3200 — — 419 0.53 457 0.62 494 0.73 528 0.83 563 0.95 595 1.07 627 1.20 656 1.32 685 1.45 712 1.58 739 1.72 766 1.86
3600 416 0.60 452 0.70 487 0.80 521 0.91 553 1.03 584 1.15 615 1.27 645 1.41 674 1.55 702 1.69 728 1.82 754 1.97 779 2.11
4000
454 0.80 487 0.90 520 1.01 550 1.13 580 1.25 610 1.38 638 1.51 666 1.65 693 1.80 720 1.95 746 2.10 771 2.26 795 2.41
4400
492 1.03 524 1.15 553 1.27 582 1.40 610 1.52 637 1.65 664 1.80 690 1.95 715 2.09 740 2.25 765 2.41 789 2.57 813 2.74
4800
531 1.31 561 1.44 588 1.57 615 1.70 641 1.85 666 1.98 691 2.12 716 2.28 740 2.44 764 2.60 787 2.76 810 2.93 833 3.11
2 HP Standard Motor & Drive
3 HP Oversize Motor & Field
Supplied Drive (2)
3 HP Oversize
Motor and Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPMBHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor and
High Static Drive Accessory
3 HP Oversize Motor
and Drive
3200 791 2.01 816 2.17 840 2.32 864 2.48 886 2.64 908 2.80 929 2.97
3600 803 2.26 827 2.41 851 2.58 874 2.74 897 2.91 919 3.08 940 3.26
4000 819 2.57 842 2.72 864 2.89 886 3.05 908 3.22 929 3.40 — —
4400 836 2.91 859 3.08 881 3.25 902 3.43 — — — — — —
4800 855 3.29 — — — — — — — — — — — —
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor & High Static Drive Accessory/Fan Speed (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave AK89 required. Field Supplied Belt
may be necessary.
2. 3 HP Oversize Motor with Field Supplied Fan Sheave BK85 Required.
Field Supplied Belt may be necessary.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged
conditions. Using the full horsepower range of our fan motors as shown in our tabular data
will not result in nuisance tripping or premature motor failure. Our product’s warranty will not
be affected.
Table 49-1 (Continued)
Table 49-2 Evaporator Fan Performance 12½ Ton YCD151C
Table 49-2 (Continued)
