Trane Voyager - Performance Data - 6, 7, 7½ Ton High Efficiency

47
Table 47-1 Evaporator Fan Performance 6, 7 Ton YC
✱✱
✱✱
✱074, YC
✱✱
✱✱
✱086C
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.25 1.50
Tons Model No. CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
1 HP Standard Motor & 1 HP Standard Motor & Sheaves
Field Supplied Low Static Drive
1
2000 680 0.45 738 0.50 794 0.55 846 0.59 894 0.63 947 0.67 1003 0.70 1055 0.72 — ———————
2250 751 0.63 804 0.69 853 0.74 903 0.80 949 0.84 992 0.88 1037 0.92 1086 0.97 1135 1.00 1181 1.03 ————
YCH074C-H 2500 824 0.84 872 0.91 917 0.97 961 1.03 1006 1.09 1047 1.14 1086 1.19 1126 1.24 1167 1.28 1212 1.33 ————
2750 899 1.11 940 1.18 984 1.25 1023 1.32 1064 1.39 1105 1.45 1142 1.51 1178 1.56 1214 1.61 1250 1.66 ————
3000 974 1.42 1010 1.50 1051 1.58 1089 1.65 1125 1.73 1162 1.80 1200 1.88 1235 1.94 1268 1.99 ——————
2 HP Oversize Motor & Sheaves
1 HP Standard Motor & Field Supplied
Low Static Drive
1
2000 615 0.37 663 0.41 710 0.45 756 0.49 799 0.52 843 0.55 884 0.58 924 0.60 965 0.62 1006 0.63 ————
YCD074C-L,H 2250 681 0.52 723 0.56 766 0.61 807 0.65 848 0.69 886 0.73 925 0.76 964 0.79 1000 0.82 1035 0.84 1126 0.90 1209 0.92
YCH074C-L 2500 748 0.69 785 0.74 824 0.79 862 0.84 899 0.89 936 0.93 971 0.98 1005 1.02 1041 1.06 1075 1.09 1154 1.16 1237 1.22
2750 816 0.91 849 0.96 884 1.02 920 1.08 954 1.13 988 1.18 1021 1.23 1053 1.28 1084 1.32 1116 1.37 1195 1.46 1266 1.54
3000 884 1.17 915 1.23 946 1.29 979 1.35 1011 1.41 1042 1.47 1073 1.52 1104 1.57 1134 1.63 1163 1.68 1236 1.80 — —
1 HP Standard Motor & Sheaves 2 HP Oversize Motor & Sheaves
1 HP Standard Motor &
Field Supplied Low Static Drive
1
1 HP Standard Motor & Sheaves
2000 680 0.45 738 0.50 794 0.55 846 0.59 894 0.63 947 0.67 1003 0.70 1055 0.72 ————————
2250 751 0.63 804 0.69 853 0.74 903 0.80 949 0.84 992 0.88 1037 0.92 1086 0.97 1135 1.00 1181 1.03 ————
YCH086C-H 2500 824 0.84 872 0.91 917 0.97 961 1.03 1006 1.09 1047 1.14 1086 1.19 1126 1.24 1167 1.28 1212 1.33 ————
2750 899 1.11 940 1.18 984 1.25 1023 1.32 1064 1.39 1105 1.45 1142 1.51 1178 1.56 1214 1.61 1250 1.66 ————
3000 974 1.42 1010 1.50 1051 1.58 1089 1.65 1125 1.73 1162 1.80 1200 1.88 1235 1.94 1268 1.99 ——————
2 HP Oversize Motor & Sheaves
7
1 HP Standard Motor & Field Supplied
Low Static Drive
1
2000 615 0.37 663 0.41 710 0.45 756 0.49 799 0.52 843 0.55 884 0.58 924 0.60 965 0.62 1006 0.63 ————
YCD086C-L,H 2250 681 0.52 723 0.56 766 0.61 807 0.65 848 0.69 886 0.73 925 0.76 964 0.79 1000 0.82 1035 0.84 1126 0.90 1209 0.92
YCH086C-L 2500 748 0.69 785 0.74 824 0.79 862 0.84 899 0.89 936 0.93 971 0.98 1005 1.02 1041 1.06 1075 1.09 1154 1.16 1237 1.22
2750 816 0.91 849 0.96 884 1.02 920 1.08 954 1.13 988 1.18 1021 1.23 1053 1.28 1084 1.32 1116 1.37 1195 1.46 1266 1.54
3000 884 1.17 915 1.23 946 1.29 979 1.35 1011 1.41 1042 1.47 1073 1.52 1104 1.57 1134 1.63 1163 1.68 1236 1.80 — —
1 HP Standard Motor & Sheaves
2 HP Oversize Motor & Sheaves
Table 47-2 Evaporator Fan Performance 7½ Ton Dual Compressor YC
✱✱
✱✱
✱091D
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.25 1.50
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor & Field Supplied
Low Static Drive
2
2 HP Standard Motor & Sheaves
2400 795 0.75 845 0.81 891 0.87 938 0.94 983 0.99 1025 1.03 1065 1.08 1107 1.12 11531.17 1200 1.21 ————
2700 884 1.05 926 1.12 970 1.19 1010 1.26 1052 1.33 1093 1.39 1131 1.44 1167 1.49 1203 1.54 1241 1.59 ————
YCH091D-H 3000 974 1.42 1010 1.50 1051 1.58 1089 1.65 1125 1.73 1162 1.80 1200 1.88 1235 1.94 1268 1.99 ——————
3300 1064 1.87 1097 1.95 1133 2.04 1170 2.13 1203 2.21 1235 2.29 1270 2.38 ——————————
3600 1154 2.41 1185 2.50 1216 2.59 1250 2.69 — ———————————————
1 HP Standard Motor
2400 721 0.62 760 0.66 801 0.71 840 0.76 879 0.80 916 0.85 952 0.89 988 0.92 10250.96 1058 0.99 1142 1.05 1226 1.10
YCD091D-L,H 2700 802 0.86 836 0.92 872 0.97 908 1.03 943 1.08 977 1.13 1011 1.17 1043 1.22 1075 1.27 1108 1.31 1186 1.40 1259 1.47
YCH091D-L 3000 884 1.17 915 1.23 946 1.29 979 1.35 1011 1.41 1042 1.47 1073 1.52 1104 1.57 1134 1.63 1163 1.68 1236 1.80 — —
3300 966 1.54 994 1.60 1022 1.67 1051 1.73 1081 1.80 1111 1.87 1139 1.93 1167 1.99 1195 2.05 1223 2.11 1289 2.26 — —
3600 1048 1.98 1075 2.06 1101 2.12 1126 2.20 1153 2.27 1181 2.34 1208 2.42 1234 2.49 ————————
2 HP Oversize Motor & Sheaves
Data includes pressure drop due to filters and wet coil.
Fan motor heat (MBH) = 3.53 x Fan Bhp.
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors, specifically designed and tested to operate reliably and continuously at all cataloged conditions.
Using the full horsepower range of our fan motors as shown in our tabular data will not result in nuisance tripping or premature motor failure. Our product’s warranty will not be affected.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
1. Field supplied Browning fan sheave AL74 and Belt A48 required.
2. Field supplied Browning motor sheave IVL34 and Belt A48 required.
6
7½
Performance 6, 7, 7½ Ton
Data
High Efficiency
✱Indicates both downflow and horizontal units.
