Table 12-1 General Data
12½ Ton Downflow and Horizontal Units 15 Ton Downflow and Horizontal Units
YC
✲150C3,C4,CWL YC✲150C3,C4,CWH YC✲180B3,B4,BWL YC✲180B3,B4,BWH
Cooling Performance
1
Gross Cooling Capacity 151,000 183,000
EER
2
8.3 8.6
8
Nominal CFM / ARI Rated CFM 5,000/4,400 6,000/5,300
ARI Net Cooling Capacity 142,000 172,000
Integrated Part Load Value
3
8.7 8.90
System Power (KW) 17.11 20.00
8
Heating Performance
4
Heating Models Low High Low High
Heating Input (Btuh) 150,000 250,000 250,000 350,000
1st Stage 100,000 175,000 175,000 250,000
Heating Output (Btuh) 122,000 203,000 203,000 284,000
1st Stage 81,000 142,000 142,000 203,000
AFUE (%)
5
(Downflow/Horizontal) 81.0 81.0 80.7 / 79.9 80.1 / 79.1
Steady State Efficiency (%) 81.0 81.0 81.0 81.0
No. Burners 1 1
No. Stages 2 2
Gas Connection Pipe Size (in.) 1/2 1/2 3/4
Compressor
No./Type 2/Climatuff® 2/Trane-H
Sound Rating (BELS)
6
9.2 9.2
Outdoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) OD .375 .375
Face Area (sq ft) 23.93 24.18
Rows/FPI 2/16 2/16
Indoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) .375 .375
Face Area (sq ft) 12.63
10
17.50
Rows/FPI 3/15 2/15
Refrigerant Control Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/1.00 NPT 1/1.00 NPT
Outdoor Fan - Type Propeller Propeller
No. Used/Diameter (in.) 1/26 2/26
Drive Type/No. Speeds Direct/1 Direct/1
CFM 7,800 10,800
No. Motors/HP 1/1.0 2/.50
Motor RPM 1125 1,100
Indoor Fan - Type FC Centrifugal FC Centrifugal
No. Used/Diameter (in.) 1/15 X 15 1/15 X 15
Drive Type/No. Speeds Belt/1 Belt/1
No. Motors 1 1
Motor HP (Standard/Oversized) 3.0/5.0 3.0/5.0
Motor RPM (Standard/Oversized) 1740/3450 1740/3450
Motor Frame Size (Standard/Oversized) 145T/145T 145T/145T
Filters - Type/Furnished Throwaway/Yes Throwaway/Yes
(No.) Size Recommended
Downflow (3) 16 X 20 X 2, (3) 20 X 20 X 2 (2) 20 X 20 X 2, (4) 20 X 25 X 2
Horizontal (4) 20 X 25 X 2 (2) 20 X 20 X 2, (4) 20 X 25 X 2
Refrigerant Charge (Lbs of R-22)
7
8.9/9.8/Circuit
9
9.5/Circuit
NOTES
1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and
includes the effect of fan motor heat. Units are suitable for operation to ±20% of nominal cfm. Rated in accordance with ARI Standard 210/240 or 360.
2. EER is rated at ARI conditions and in accordance with ARI Standard 210/240 or 360.
3. Integrated Part Load Value is based on ARI Standard 210/240 or 360. Units are rated at 80° F ambient, 80° F entering dry bulb, and 67° F entering wet bulb at ARI rated cfm.
4. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards. Ratings
shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
5. AFUE is rated in accordance with DOE test procedures.
6. Sound Rating is rated in accordance with ARI Standard 270 or 370.
7. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
8. Horizontal models have 8.8 EER and 19.55 system power KW.
9. Refrigerant charge for Horizontal units is 9.4 per circuit.
10. Face Area for horizontal models is 12.36.
✲Indicates Downflow and Horizontal.
General 12½, 15 Ton
