Trane Voyager - Performance Data - 10,,,, 12½ Ton Standard Efficiency

42
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor &
Field Supplied Low Static Drive (1) 3 HP Standard Motor & Drive (2)
4000 604 1.11 647 1.27 687 1.44 723 1.60 756 1.75 787 1.90 818 2.06 848 2.23 877 2.40 906 2.58 933 2.77 960 2.96 987 3.15
4500 669 1.53 708 1.71 745 1.90 780 2.09 811 2.27 841 2.44 869 2.60 896 2.77 923 2.96 950 3.15 977 3.34 1002 3.54 1027 3.75
5000 735 2.06 770 2.25 804 2.46 837 2.67 868 2.89 897 3.08 923 3.27 949 3.45 974 3.64 999 3.83 1023 4.03 1048 4.24 1072 4.46
5500 802 2.70 834 2.90 865 3.13 896 3.36 926 3.60 954 3.83 980 4.04 1004 4.25 1028 4.46 1051 4.66 1074 4.87 1096 5.07 1119 5.30
6000 869 3.46 898 3.68 928 3.92 956 4.17 984 4.42 1011 4.68 1037 4.94 1061 5.18 1084 5.40 1106 5.63 — — — — — —
5 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
(2) 5 HP Oversize Motor & Drive (3)
4000 1013 3.34 1038 3.54 1063 3.74 1087 3.95 1111 4.10 1134 4.37 1156 4.58
4500 1052 3.96 1076 4.17 1100 4.38 1123 4.60 1146 4.82 1168 5.05 1190 5.28
5000 1095 4.68 1118 4.90 1140 5.13 1163 5.36 1184 5.60 — — — —
5500 1141 5.53 — — — — — — — — — — — —
6000 — — — — — — — — — — — — — —
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.00 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
Standard Motor & Field Supplied Low Static Drive (1) 3 HP Standard Motor and Drive
3200 — — 759 1.21 790 1.31 818 1.40 844 1.50 870 1.59 894 1.69 918 1.79 941 1.89 964 1.98 986 2.08 1007 2.17 1029 2.27
3600 807 1.53 838 1.65 867 1.77 893 1.88 918 1.99 942 2.10 965 2.21 987 2.32 1009 2.43 1030 2.54 1051 2.65 1071 2.75 1091 2.86
4000 891 2.06 918 2.20 946 2.34 971 2.47 994 2.59 1017 2.71 1038 2.83 1059 2.95 1080 3.07 1100 3.19 1119 3.31 1138 3.44 1157 3.56
4400 975 2.72 999 2.86 1025 3.02 1049 3.17 1071 3.31 1092 3.44 1113 3.57 1133 3.70 1152 3.83 1171 3.97 1190 4.10 1208 4.23 1226 4.37
4800 1059 3.51 1082 3.65 1105 3.82 1128 3.99 1149 4.16 1170 4.30 1189 4.45 1208 4.59 1226 4.73 1244 4.87 1262 5.02 1279 5.16 1296 5.31
5 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
3 HP Standard Motor and Drive
3200 1049 2.37 1070 2.48 1090 2.59 1110 2.70 1130 2.81 1149 2.93 1170 3.06
3600 1111 2.96 1130 3.07 1149 3.18 1167 3.29 1186 3.41 1204 3.53 1222 3.65
4000 1175 3.68 1194 3.80 1211 3.92 1229 4.03 1246 4.15 1264 4.27 1281 4.39
4400 1243 4.51 1260 4.64 1277 4.77 1294 4.91 1311 5.04 1327 5.17 1343 5.29
4800 1313 5.46 1329 5.60 — — — — — — — (2) — —
5 HP Oversize Motor & Drive
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
1. Field Supplied Fan Sheave BK90 Required. Field Supplied Belt may be Necessary.
2 3 HP Standard Motor with Field Supplied Motor Sheave 1VP44 Required. Field Supplied Belt may be Necessary.
3. 5 HP Oversize Motor with Field Supplied Motor Sheave 1VP50 Required. Field Supplied Belt may be Necessary.
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
Table 42-1 (Continued)
Performance 10
, ,
, ,
, 12½ Ton
Data
Standard Efficiency
Table 42-1 Evaporator Fan Performance 10 Ton YCH120C
Table 42-2 Evaporator Fan Performance 12 1/2 Ton YCD150C
Table 42-2 (Continued)
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave BK90 Required. Field Supplied Belt may be Necessary.
2. 5 HP Oversize Motor with Field Supplied Fan Sheave BK120 Required.
Field Supplied Belt may be Necessary.
