36
Performance 15, 17½
,,
,,
, Ton
Data
High Efficiency
Ambient Temperature
Table 36-2 Gross Cooling Capacities (MBH) 17½ Ton Three Phase YC
✱✱
✱✱
✱211C3, C4, CW
Table 36-1 Gross Cooling Capacities (MBH) 15 Ton Three Phase YC
✱✱
✱✱
✱181C3, C4, CW
Ambient Temperature
Enter 85 95 105 115
Dry Entering Wet Bulb
Airflow Bulb 61 67 73 61 67 73 61 67 73 61 67 73
CFM (F) MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC MBH SHC
75 172.0 144.0 195.0 112.0 205.0 75.3 159.0 138.0 185.0 107.0 201.0 72.0 146.0 131.0 172.0 101.0 193.0 67.9 133.0 122.0 156.0 94.1 182.0 63.2
5400 80 175.0 170.0 195.0 138.0 208.0 103.0 164.0 162.0 185.0 134.0 202.0 99.8 152.0 152.0 172.0 128.0 194.0 95.3 141.0 141.0 157.0 121.0 183.0 90.4
85 185.0 185.0 196.0 164.0 210.0 126.0 176.0 176.0 186.0 161.0 204.0 126.0 165.0 165.0 173.0 156.0 195.0 122.0 154.0 154.0 159.0 147.0 183.0 117.0
90 196.0 196.0 196.0 196.0 212.0 148.0 188.0 188.0 189.0 184.0 205.0 149.0 178.0 178.0 179.0 178.0 195.0 147.0 167.0 167.0 167.0 167.0 183.0 144.0
75 177.0 153.0 197.0 117.0 207.0 76.7 164.0 147.0 189.0 112.0 202.0 73.2 145.0 145.0 176.0 106.0 195.0 69.2 137.0 130.0 160.0 99.3 185.0 64.6
6000 80 182.0 180.0 198.0 144.0 209.0 105.0 170.0 170.0 189.0 142.0 204.0 103.0 159.0 159.0 176.0 136.0 196.0 99.4 147.0 147.0 161.0 129.0 185.0 94.5
85 192.0 192.0 200.0 172.0 212.0 128.0 183.0 183.0 190.0 171.0 206.0 129.0 173.0 173.0 172.0 172.0 197.0 127.0 161.0 161.0 164.0 156.0 186.0 124.0
90 201.0 201.0 201.0 201.0 214.0 152.0 194.0 194.0 195.0 194.0 207.0 153.0 185.0 185.0 185.0 185.0 198.0 154.0 174.0 174.0 174.0 174.0 187.0 152.0
75 181.0 162.0 200.0 121.0 208.0 78.0 168.0 156.0 191.0 117.0 204.0 74.4 151.0 151.0 179.0 111.0 196.0 70.5 141.0 137.0 163.0 104.0 187.0 66.0
6600 80 187.0 187.0 200.0 149.0 210.0 106.0 176.0 176.0 192.0 148.0 206.0 105.0 165.0 165.0 179.0 144.0 198.0 103.0 153.0 153.0 164.0 137.0 187.0 98.4
85 197.0 197.0 202.0 179.0 213.0 131.0 189.0 189.0 194.0 180.0 208.0 132.0 179.0 179.0 182.0 173.0 199.0 132.0 167.0 167.0 169.0 165.0 188.0 129.0
90 205.0 205.0 205.0 203.0 215.0 156.0 199.0 199.0 199.0 199.0 209.0 158.0 191.0 191.0 191.0 191.0 201.0 160.0 181.0 181.0 180.0 180.0 190.0 160.0
75 185.0 170.0 203.0 126.0 208.0 78.8 167.0 167.0 193.0 121.0 205.0 75.7 158.0 153.0 181.0 116.0 198.0 71.8 145.0 144.0 166.0 109.0 188.0 67.2
7200 80 191.0 191.0 202.0 153.0 211.0 107.0 182.0 182.0 194.0 155.0 207.0 107.0 171.0 171.0 182.0 151.0 200.0 106.0 158.0 158.0 168.0 145.0 189.0 102.0
85 201.0 201.0 204.0 184.0 214.0 132.0 194.0 194.0 194.0 194.0 209.0 142.0 184.0 184.0 186.0 181.0 201.0 137.0 173.0 173.0 173.0 173.0 190.0 134.0
90 208.0 208.0 208.0 208.0 216.0 159.0 203.0 203.0 203.0 203.0 210.0 162.0 195.0 195.0 195.0 195.0 203.0 166.0 185.0 185.0 185.0 185.0 192.0 167.0
NOTES:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
2. MBH = Total Gross Capacity
3. SHC = Sensible Heat Capacity
NOTES:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
2. MBH = Total Gross Capacity
3. SHC = Sensible Heat Capacity
Enter 85 95 105 115
Dry Entering Wet Bulb
Airflow Bulb 61 67 73 61 67 73 61 67 73 61 67 73
CF M (F ) MB H SHC MBH SHC MBH SHC MBH SHC MB H SHC MBH SHC MBH SHC MB H S HC MBH SHC MBH SHC MBH SHC MBH SHC
75 200.0 169.0 224.0 130.0 233.0 86.2 184.0 162.0 215.0 125.0 231.0 83.3 169.0 154.0 199.0 118.0 226.0 79.3 147.0 147.0 180.0 113.0 214.0 74.2
6300 80 202.0 202.0 225.0 161.0 236.0 118.0 190.0 190.0 216.0 158.0 234.0 117.0 177.0 177.0 200.0 151.0 227.0 112.0 164.0 164.0 181.0 142.0 214.0 107.0
85 216.0 216.0 227.0 191.0 239.0 143.0 206.0 206.0 217.0 190.0 236.0 146.0 193.0 193.0 202.0 184.0 228.0 144.0 180.0 180.0 185.0 176.0 215.0 139.0
90 227.0 227.0 230.0 221.0 242.0 169.0 220.0 220.0 220.0 220.0 239.0 175.0 209.0 209.0 209.0 209.0 229.0 174.0 196.0 196.0 195.0 195.0 217.0 171.0
75 205.0 180.0 226.0 134.0 234.0 87.6 190.0 172.0 219.0 131.0 233.0 84.8 174.0 164.0 204.0 124.0 228.0 80.8 155.0 155.0 184.0 116.0 218.0 76.0
7000 80 210.0 210.0 228.0 167.0 237.0 119.0 198.0 198.0 220.0 167.0 236.0 120.0 185.0 185.0 205.0 160.0 229.0 117.0 171.0 171.0 186.0 152.0 218.0 112.0
85 223.0 223.0 230.0 199.0 241.0 145.0 215.0 215.0 222.0 202.0 238.0 150.0 202.0 202.0 209.0 197.0 231.0 150.0 188.0 188.0 191.0 189.0 219.0 147.0
90 232.0 232.0 233.0 230.0 244.0 173.0 227.0 227.0 227.0 227.0 241.0 180.0 218.0 218.0 218.0 218.0 232.0 182.0 205.0 205.0 204.0 204.0 221.0 181.0
75 210.0 190.0 228.0 138.0 235.0 88.9 195.0 183.0 222.0 137.0 234.0 86.0 179.0 175.0 208.0 130.0 229.0 82.4 161.0 161.0 188.0 122.0 220.0 77.7
7700 80 217.0 217.0 231.0 173.0 239.0 120.0 206.0 206.0 223.0 174.0 237.0 121.0 192.0 192.0 209.0 169.0 231.0 121.0 178.0 178.0 190.0 161.0 221.0 116.0
85 228.0 228.0 232.0 206.0 242.0 148.0 221.0 221.0 226.0 211.0 240.0 153.0 210.0 210.0 214.0 209.0 234.0 156.0 196.0 196.0 195.0 195.0 222.0 154.0
90 235.0 235.0 235.0 235.0 245.0 176.0 232.0 232.0 232.0 232.0 243.0 185.0 224.0 224.0 224.0 224.0 235.0 189.0 213.0 213.0 212.0 212.0 224.0 191.0
75 214.0 200.0 230.0 141.0 236.0 90.3 200.0 193.0 224.0 141.0 235.0 87.4 181.0 181.0 211.0 136.0 230.0 83.8 166.0 166.0 191.0 128.0 222.0 79.2
8400 80 222.0 222.0 232.0 177.0 239.0 133.0 213.0 213.0 226.0 181.0 238.0 123.0 199.0 199.0 213.0 178.0 233.0 124.0 184.0 184.0 194.0 170.0 223.0 121.0
85 231.0 231.0 234.0 211.0 243.0 149.0 226.0 226.0 229.0 220.0 241.0 155.0 216.0 216.0 216.0 216.0 235.0 161.0 203.0 203.0 202.0 202.0 224.0 162.0
90 238.0 238.0 238.0 238.0 246.0 178.0 235.0 235.0 235.0 235.0 244.0 189.0 229.0 229.0 229.0 229.0 237.0 195.0 219.0 219.0 219.0 219.0 227.0 199.0
