External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor & Field
Supplied Low Static Drive (1)
2 HP Standard Motor & Drive 2 HP Standard Motor & High
Static Drive Accessory
3200 — — 447 0.48 503 0.60 551 0.73 595 0.85 635 0.96 672 1.07 706 1.18 739 1.29 770 1.39 799 1.50 825 1.62 853 1.74
3600 407 0.45 473 0.60 527 0.75 575 0.89 618 1.03 657 1.16 694 1.29 728 1.41 760 1.54 791 1.66 820 1.78 848 1.90 875 2.02
4000 436 0.57 500 0.75 551 0.92 598 1.08 641 1.23 680 1.38 716 1.53 750 1.67 782 1.82 812 1.96 841 2.09 869 2.23 896 2.36
4400 465 0.72 524 0.92 577 1.11 623 1.29 665 1.46 703 1.63 739 1.80 772 1.96 804 2.12 834 2.28 863 2.43 891 2.59 917 2.74
4800 496 0.89 551 1.11 604 1.32 648 1.52 689 1.72 727 1.90 762 2.09 795 2.27 827 2.45 857 2.63 885 2.80 913 2.97 939 3.14
2 HP Standard Motor & Drive 3 HP Oversize Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor & High Static Drive
Accessory
3 HP Oversize Motor &
Drive
3200 881 1.86 908 1.99 933 2.13 957 2.28 980 2.44 1003 2.59 1026 2.75
3600 900 2.14 924 2.27 948 2.41 973 2.55 998 2.69 1022 2.84 1044 3.00
4000 922 2.50 947 2.63 971 2.76 994 2.89 1016 3.04 1037 3.19 1059 3.35
4400 943 2.89 968 3.04 992 3.19 1015 3.33 1038 3.45 — — — —
4800 965 3.31 989 3.45 — — — — — — — — — —
3 HP Oversize Motor
and Drive
Performance 8½, 10 Ton
Data
High Efficiency
✱Indicates both downflow and horizontal units.
Table 48-1 Evaporator Fan Performance 8½ Ton YC
✲✲
✲✲
✲103C
Trane’s factory supplied motors, in commercial equipment, are definite purpose
motors, specifically designed and tested to operate reliably and continuously at all
cataloged conditions. Using the full horsepower range of our fan motors as shown in
our tabular data will not result in nuisance tripping or premature motor failure. Our
product’s warranty will not be affected.
Table 48-2 (Continued)
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor & High Static Drive Accessory/Fan Speed (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave AK89 required. Field Supplied Belt
may be necessary.
External Static Pressure (Inches of Water)
.10 .20 .30 .40 .50 .60 .70 .80 .90 1.00 1.10 1.20 1.30
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard Motor &
Field Supplied Low Static Drive (1) 2 HP Standard Motor & Drive
2720 — — 502 0.54 545 0.62 584 0.69 619 0.76 650 0.83 680 0.90 712 0.99 743 1.08 772 1.17 800 1.27 826 1.36 852 1.46
3060 510 0.64 545 0.72 583 0.80 620 0.89 655 0.98 687 1.06 715 1.14 742 1.21 770 1.30 798 1.39 826 1.49 852 1.60 877 1.71
3400 561 0.86 590 0.94 624 1.03 658 1.13 691 1.23 723 1.32 752 1.41 779 1.50 803 1.59 827 1.67 852 1.76 878 1.87 903 1.98
3740 611 1.13 637 1.21 666 1.31 698 1.41 729 1.52 759 1.63 788 1.73 815 1.83 840 1.93 864 2.03 886 2.13 908 2.22 930 2.31
4080 663 1.45 686 1.54 711 1.64 739 1.74 768 1.86 797 1.98 824 2.09 851 2.21 877 2.32 901 2.43 923 2.54 944 2.65 965 2.75
3 HP Oversized Motor & Drive
External Static Pressure (Inches of Water)
1.40 1.50 1.60 1.70 1.80 1.90 2.00
CFM RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP RPM BHP
2 HP Standard 2 HP Standard Motor & High Static Drive Accessory
Motor & Drive
2720 876 1.55 901 1.50 924 1.76 947 1.87 970 1.98 993 2.10 1015 2.22
3060 902 1.81 925 1.92 948 2.02 970 2.13 992 2.24 1014 2.35 1035 2.47
3400 927 2.10 951 2.22 974 2.33 996 2.45 1017 2.57 1038 2.68 — —
3740 953 2.42 977 2.54 999 2.67 1021 2.80 1043 2.93 — — — —
4080 985 2.85 1005 2.95 1026 3.06 1047 3.19 — — — — — —
3 HP Oversized Motor & Drive
Trane’s factory supplied motors, in commercial equipment, are definite purpose motors,
specifically designed and tested to operate reliably and continuously at all cataloged
conditions. Using the full horsepower range of our fan motors as shown in our tabular
data will not result in nuisance tripping or premature motor failure. Our product’s warranty
will not be affected.
Table 48-1 (Continued)
Table 48-2 Evaporator Fan Performance 10 Ton YCD121C
For Standard Evaporator Fan Speed (RPM), reference Table 53-1.
For Standard Motor and High Static Drive (RPM), reference Table 53-2.
For Oversize Evaporator Fan Speed (RPM), reference Table 53-3.
NOTES:NOTES:
NOTES:NOTES:
NOTES:
Data includes pressure drop due to filters and wet coils.
Fan motor heat (MBH) = 3.15 x Fan Bhp.
1. Field Supplied Fan Sheave AK89 required. Field Supplied Belt
may be necessary.
