35
Performance 10, 12½ Ton
Data
High Efficiency
Table 35-2 Gross Cooling Capacities (MBH) 12½ Ton Three Phase YC
✱✱
✱✱
✱151C3, C4, CW
Table 35-1 Gross Cooling Capacities (MBH) 10 Ton Three Phase YC
✱✱
✱✱
✱121C3, C4, CW
75 117.0 99.3 131.0 76.4 137.0 50.5 106.0 93.7 124.0 72.8 134.0 48.0 95.1 88.5 112.0 68.1 129.0 45.0 81.1 81.1 100.0 62.7 120.0 41.5
3600 80 119.0 119.0 131.0 93.6 139.0 68.7 110.0 110.0 125.0 91.9 136.0 67.2 101.0 101.0 113.0 86.6 130.0 64.3 92.6 92.6 101.0 81.2 120.0 60.7
85 127.0 127.0 132.0 111.0 140.0 83.6 120.0 120.0 125.0 111.0 137.0 84.3 110.0 110.0 114.0 106.0 130.0 82.5 101.0 101.0 102.0 101.0 120.0 79.5
90 133.0 133.0 134.0 129.0 142.0 98.8 128.0 128.0 128.0 128.0 138.0 101.0 120.0 120.0 120.0 120.0 131.0 100.0 110.0 110.0 110.0 110.0 121.0 98.4
75 120.0 106.0 132.0 78.6 138.0 51.3 109.0 100.0 127.0 76.2 136.0 48.9 97.8 94.8 116.0 71.5 130.0 45.9 90.6 90.6 102.0 65.8 123.0 42.7
4000 80 124.0 124.0 133.0 97.2 140.0 69.7 115.0 115.0 127.0 96.9 137.0 69.2 106.0 106.0 116.0 92.6 131.0 67.2 96.7 96.7 103.0 87.0 123.0 63.8
85 130.0 130.0 134.0 116.0 141.0 85.4 125.0 125.0 128.0 117.0 138.0 86.9 116.0 116.0 118.0 114.0 132.0 86.2 106.0 106.0 106.0 106.0 123.0 84.6
90 136.0 136.0 136.0 134.0 143.0 101.0 132.0 132.0 132.0 132.0 140.0 105.0 125.0 125.0 125.0 125.0 133.0 105.0 116.0 116.0 116.0 116.0 124.0 105.0
75 123.0 112.0 134.0 80.8 139.0 52.2 112.0 107.0 128.0 79.5 136.0 49.8 99.9 99.9 118.0 75.3 132.0 46.9 91.1 91.1 104.0 69.4 124.0 43.7
4400 80 127.0 127.0 135.0 100.0 141.0 75.6 120.0 120.0 129.0 102.0 138.0 70.6 110.0 110.0 119.0 98.4 133.0 69.5 100.0 100.0 105.0 92.6 125.0 66.7
85 133.0 133.0 136.0 120.0 142.0 87.0 128.0 128.0 130.0 123.0 139.0 89.2 121.0 121.0 121.0 121.0 133.0 89.3 110.0 110.0 110.0 110.0 125.0 89.0
90 138.0 138.0 138.0 138.0 144.0 104.0 134.0 134.0 134.0 134.0 141.0 108.0 129.0 129.0 129.0 129.0 134.0 110.0 121.0 121.0 121.0 121.0 126.0 111.0
75 125.0 118.0 135.0 82.6 140.0 53.1 115.0 113.0 130.0 82.1 137.0 50.7 103.0 103.0 120.0 78.9 132.0 47.8 94.0 94.0 106.0 72.9 125.0 44.5
4800 80 130.0 130.0 136.0 103.0 141.0 78.3 124.0 124.0 130.0 106.0 139.0 71.7 114.0 114.0 121.0 104.0 134.0 71.4 104.0 104.0 108.0 98.2 126.0 69.3
85 135.0 135.0 137.0 124.0 143.0 88.4 131.0 131.0 132.0 129.0 140.0 91.2 125.0 125.0 125.0 125.0 134.0 92.2 115.0 115.0 115.0 115.0 126.0 92.9
90 139.0 139.0 139.0 139.0 145.0 106.0 137.0 137.0 137.0 137.0 142.0 111.0 132.0 132.0 132.0 132.0 136.0 114.0 125.0 125.0 125.0 125.0 128.0 116.0
75 137.0 116.0 157.0 90.2 166.0 60.8 127.0 110.0 151.0 87.1 163.0 58.5 116.0 105.0 140.0 82.3 158.0 55.8 106.0 99.7 128.0 80.6 152.0 52.8
4500 80 140.0 139.0 158.0 111.0 167.0 82.9 130.0 130.0 151.0 109.0 164.0 80.8 122.0 122.0 141.0 104.0 159.0 77.8 114.0 114.0 128.0 98.5 152.0 74.6
85 149.0 149.0 158.0 132.0 169.0 100.0 142.0 142.0 151.0 131.0 165.0 99.4 133.0 133.0 141.0 126.0 159.0 98.2 125.0 125.0 130.0 121.0 152.0 96.0
90 158.0 158.0 160.0 153.0 170.0 118.0 152.0 152.0 154.0 152.0 166.0 118.0 145.0 145.0 145.0 145.0 160.0 118.0 137.0 137.0 137.0 137.0 153.0 117.0
75 141.0 123.0 159.0 93.4 167.0 61.6 131.0 117.0 154.0 90.9 164.0 59.4 120.0 112.0 144.0 86.6 159.0 56.8 109.0 107.0 132.0 81.0 153.0 53.7
5000 80 145.0 145.0 160.0 116.0 168.0 84.1 136.0 136.0 154.0 114.0 165.0 82.4 128.0 128.0 144.0 110.0 161.0 80.9 119.0 119.0 132.0 105.0 154.0 77.5
85 155.0 155.0 161.0 138.0 170.0 103.0 148.0 148.0 155.0 138.0 166.0 102.0 140.0 140.0 145.0 135.0 161.0 102.0 131.0 131.0 134.0 129.0 154.0 100.0
90 162.0 162.0 163.0 160.0 172.0 121.0 157.0 157.0 157.0 157.0 168.0 122.0 151.0 151.0 151.0 151.0 163.0 123.0 143.0 143.0 143.0 143.0 155.0 122.0
75 145.0 129.0 161.0 95.8 168.0 62.6 134.0 124.0 156.0 94.4 165.0 60.4 123.0 119.0 147.0 90.4 161.0 57.8 112.0 112.0 135.0 85.1 154.0 54.6
5500 80 150.0 150.0 162.0 119.0 169.0 85.2 142.0 142.0 156.0 119.0 167.0 84.0 133.0 133.0 147.0 116.0 162.0 82.4 124.0 124.0 135.0 111.0 155.0 80.1
85 158.0 158.0 163.0 143.0 172.0 104.0 153.0 153.0 157.0 144.0 168.0 104.0 146.0 146.0 149.0 143.0 163.0 105.0 137.0 137.0 137.0 137.0 156.0 104.0
90 165.0 165.0 165.0 165.0 173.0 123.0 161.0 161.0 161.0 161.0 170.0 126.0 156.0 156.0 156.0 156.0 164.0 127.0 149.0 149.0 149.0 149.0 157.0 127.0
75 148.0 136.0 162.0 97.9 168.0 63.5 137.0 131.0 157.0 97.1 166.0 61.4 126.0 125.0 150.0 94.3 162.0 58.9 116.0 116.0 138.0 89.0 155.0 55.6
6000 80 154.0 154.0 163.0 123.0 170.0 86.2 147.0 147.0 158.0 124.0 168.0 85.8 138.0 138.0 150.0 122.0 162.0 83.3 128.0 128.0 138.0 117.0 156.0 82.2
85 161.0 161.0 165.0 147.0 172.0 106.0 157.0 157.0 160.0 150.0 169.0 106.0 151.0 151.0 152.0 150.0 164.0 107.0 142.0 142.0 142.0 142.0 158.0 107.0
90 167.0 167.0 167.0 167.0 174.0 126.0 164.0 164.0 164.0 164.0 171.0 128.0 159.0 159.0 159.0 159.0 166.0 131.0 153.0 153.0 153.0 153.0 159.0 132.0
Ambient Temperature
Ent er 85 95 10 5 115
Dry Entering Wet Bulb
Airflow Bulb 61 67 73 61 67 73 61 67 73 61 67 73
CF M ( F ) MBH SHC MBH SHC MB H SHC MB H SHC MB H SHC MBH SHC MB H S HC MB H SHC MB H SHC MB H SHC MBH SHC MB H SHC
MBH SHC MBH SHC MBH SHC
NOTES:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
2. MBH = Total Gross Capacity
3. SHC = Sensible Heat Capacity
NOTES:
1. All capacities shown are gross and have not considered indoor fan heat. To obtain net cooling subtract indoor fan heat.
2. MBH = Total Gross Capacity
3. SHC = Sensible Heat Capacity
Amb ient Temp erat ure
Ent er 85 95 105 115
Dry Entering Wet Bulb
Airflow Bulb 61 67 73 61 67 73 61 67 73 61 67 73
CF M ( F ) MBH SHC MB H S HC MB H SHC MB H SHC MB H SHC MB H SHC MBH SHC MB H SHC MBH SHC MB H SHC MBH SHC MBH S HCMBH SHC MBH SHC MBH SHC
