19
Table 19-1 General Data
12½ Ton Downflow and Horizontal Units 15 Ton Downflow and Horizontal Units
YC
✲151C3,C4,CW YC✲181C3,C4,CW
Cooling Performance
1
Gross Cooling Capacity 154,000 189,000
EER
2
11.30 11.50
Nominal CFM / ARI Rated CFM 5,000 / 4400 6,000 / 5300
ARI Net Cooling Capacity 147,000 180,000
Integrated Part Load Value
3
11.5 13.3
System Power (KW) 13.01 15.65
Heating Performance
4
Heating Models Low High Low High
Heating Input (Btuh) 150,000 250,000 250,000 350,000
1st Stage 100,000 175,000 175,000 250,000
Heating Output (Btuh) 122,000 203,000 203,000 284,000
1st Stage 81,000 142,000 142,000 203,000
AFUE%
5
(Downflow/Horizontal) 81.0 / 81.0 80.7 / 79.9 80.7 / 79.9 80.1 / 79.1
Steady State Efficiency (%)
5
81.0 81.0 81.0 81.0
No. Burners 1 1 1 1
No. Stages 2 2 2 2
Gas Connection Pipe Size (in.) 1/2 1/2 1/2 3/4
Compressor
No./Type 2/Copeland Scroll 2/Trane 3-D® Scroll/Climatuff®
Sound Rating (BELS)
6
9.2 9.2
Outdoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) OD 0.375 0.375
Face Area (sq ft) 27.12 35.30
Rows/FPI 3/16 3/16
Indoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) 0.375 0.375
Face Area (sq ft) 17.50 26.00
Rows/FPI 3/15 3/15
Refrigerant Control Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/1.0 NPT 1/1.0 NPT
Outdoor Fan - Type Propeller Propeller
No. Used/Diameter (in.) 2/26 2/26
Drive Type/No. Speeds Direct/1 Direct/1
CFM 10,400 11,000
No. Motors/HP 2/.50 2/.50
Motor RPM 1100 1100
Indoor Fan - Type FC Centrifugal FC Centrifugal
No. Used/Diameter (in.) 1/ 15 x 15 1/18 x 18
Drive Type/No. Speeds Belt/1 Belt/1
No. Motors 1 1
Motor HP (Standard/Oversized) 3.0/5.0 3.0/5.0
Motor RPM (Standard/Oversized) 1740/3450 1740/3450
Motor Frame Size (Standard/Oversized) 145T/145T 145T/145T
Filters - Type Throwaway Throwaway
Furnished? Yes Yes
(No.) Size Recommended (2)20 X 20 X 2/(4)20 X 25 X 2 (4)20 X 20 X 2/(4)20 X 25 X 2
8
Refrigerant Charge (Lbs of R-22)
7
/Circuit 15.0/13.8 26.6/10.9
NOTES:
1. Cooling Performance is rated at 95F ambient, 80F entering dry bulb, 67F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and
includes the effect of fan motor heat. Rated in accordance with ARI Standard 210/240 or 360
2. EER is rated at ARI conditions and in accordance with DOE test procedures.
3. Integrated Part Load Value is based On ARI Standard 210/240 or 360. Units are rated at 80F ambient, 80F entering dry bulb, and 67F entering wet bulb at ARI rated cfm.
4. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards. Ratings
shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
5. AFUE and Steady State Efficiency is rated in accordance with DOE test procedures.
6. Sound Rating is rated in accordance with ARI Standard 270 or 370.
7. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
8. Horizontal Models have 8 -20 x 25 x 2
✲Indicates both downflow and horizontal units.
General 12½
,,
,,
, 15 Ton
Data
High Efficiency
