Trane Voyager - General Data - 7,,,,, 7½ Ton High Efficiency

17
✲Indicates both downflow and horizontal units.
Table 17-1 General Data
7 Ton Downflow and Horizontal Units 7½ Ton Downflow and Horizontal Units
YC
✲086C3,C4 YC✲091D3,D4
Cooling Performance
1
Gross Cooling Capacity 82,000 86,000
EER
2
9.50 10.00
9
Nominal CFM / ARI Rated CFM 2,500/2,188 3,000/2,625
ARI Net Cooling Capacity 78,000 81,000
9
Integrated Part Load Value
3
10.10
9
System Power (KW) 8.21 8.10
9
Heating Performance
4
Heating Models Low High Low High
Heating Input (Btuh) 120,000 205,000 120,000 205,000
1st Stage (2 Stage Only) — 150,000 — 150,000
Heating Output (Btuh) 97,000 166,000 97,000 166,000
1st Stage (2 Stage Only) — 122,000 — 122,000
AFUE%
5
81.0 81.0 81.0 81.0
Steady State Efficiency (%)
5
81.0 81.0 81.0 81.0
No. Burners 1 1 1 1
No. Stages 1 2 1 2
Gas Connection Pipe Size (in.) 1/2 1/2 1/2 1/2
Compressor
No./Type 1/Climatuff® 2/Climatuff
Sound Rating (BELS)
6
8.80 8.80
Outdoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) OD 0.375 0.375
Face Area (sq ft) 14.00 14.00
Rows/FPI 2/16 2/16
Indoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) 0.375 0.375
Face Area (sq ft) 7.88 7.88
Rows/FPI 3/15 3/15
Refrigerant Control Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/3/4 PVC 1/ 3/4 PVC
Outdoor Fan - Type Propeller Propeller
No. Used/Diameter (in.) 1/24 1/24
Drive Type/No. Speeds Direct/1 Direct/1
CFM 5,620 5,620
No. Motors/HP 1/.50 1/.50
Motor RPM 1075 1075
Indoor Fan - Type FC Centrifugal FC Centrifugal
No. Used/Diameter (in.) 1/12 x 9 1/ 12 x 9
Drive Type/No. Speeds BELT/1 BELT/1
No. Motors 1 1
Motor HP (Standard/Oversized) 1.0/2.0 1.0/2.0
8
Motor RPM (Standard/Oversized) 1725/1725 1725/1725
8
Motor Frame Size (Standard/Oversized) 56/56 56/56
8
Filters - Type Throwaway Throwaway
Furnished? Yes Yes
(No.) Size Recommended (3)16 X 25 X 1 (3)16 X 25 X 1
Refrigerant Charge (Lbs of R-22)
7
11.60 6.40/Circuit
NOTES:
1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net
and includes the effect of fan motor heat. Rated in accordance with ARI Standard 210/240 or 360
2. EER is rated at ARI conditions and in accordance with DOE test procedures.
3. Integrated Part Load Value is based On ARI Standard 210/240 or 360. Units are rated at 80 F ambient, 80 F entering dry bulb, and 67 F entering wet bulb at ARI rated cfm.
4. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards.
Ratings shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
5. AFUE and Steady State Efficiency is rated in accordance with DOE test procedures.
6. Sound Rating is rated in accordance with ARI Standard 270 or 370.
7. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
8. YCH High Heat models 2.0 is the Standard Motor.
9. YCH091, High Heat EER is 9.70, IPLV is 9.8 and System Power is 8.25 KW, and ARI Net Cooling Capacity is 80,000 Btuh.
