Trane Voyager - Dimensional Data - 3-7½ Ton Accessories

84
Fresh Air Hood
(Manual)
Economizer
End Panel
Power Exhaust with Downflow
Economizers Only. End Panel View
Power Exhaust with
Downflow
Economizers Only. Side View
Standard End Panel
Of Unit
Economizer Hood
Note:
When applying economizer to horizontal units,
connecting ductwork must be run full size to allow
proper operation of Economizer Damper.
Dimensional
Data
3-7½ Ton
Accessories
