Trane Voyager - General Data - 8½,,,,, 10 Ton High Efficiency

18
Table 18-1 General Data
8½ Ton Downflow and Horizontal Units 10 Ton Downflow and Horizontal Units
YC
✲103C3,C4,CW YC✲121C3,C4,CW
Cooling Performance
1
Gross Cooling Capacity 106,000 127,000
EER
2
11.00 11.50
Nominal CFM / ARI Rated CFM 3,400 / 3,000 4,000 / 3,500
ARI Net Cooling Capacity 101,000 120,000
Integrated Part Load Value
3
11.9 12.4
System Power (KW) 9.18 10.43
Heating Performance
4
Heating Models Low High Low High
Heating Input (Btuh) 150,000 250,000 150,000 250,000
1st Stage 100,000 175,000 100,000 175,000
Heating Output (Btuh) 122,000 203,000 122,000 203,000
1st Stage 81,000 142,000 81,000 142,000
AFUE%
5
81.0 81.0 81.0 81.0
Steady State Efficiency (%)
5
81.0 81.0 81.0 81.0
No. Burners 1 1 1 1
No. Stages 2 2 2 2
Gas Connection Pipe Size (in.) 1/2 1/2 1/2 1/2
Compressor
No./Type 2/Copeland Scroll 2/Climatuff®
Sound Rating (BELS)
6
9.0 9.2
Outdoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) OD 0.375 0.375
Face Area (sq ft) 23.93 28.21
Rows/FPI 2/16 2/16
Indoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) 0.375 0.375
Face Area (sq ft) 12.63
8
17.50
Rows/FPI 3/15 3/15
Refrigerant Control Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/1.0 NPT 1/1.0 NPT
Outdoor Fan - Type Propeller Propeller
No. Used/Diameter (in.) 1/26 2/26
Drive Type/No. Speeds Direct/1 Direct/1
CFM 7,100 10,800
No. Motors/HP 1/1.0 2/0.5
Motor RPM 1125 1100
Indoor Fan - Type FC Centrifugal FC Centrifugal
No. Used/Diameter (in.) 1/15 x 11 1/15 x 15
Drive Type/No. Speeds Belt/1 Belt/1
No. Motors 1 1
Motor HP (Standard/Oversized) 2.0/3.0 2.0/3.0
Motor RPM (Standard/Oversized) 1740/1740 1740/1740
Motor Frame Size (Standard/Oversized) 145T/145T 145T/145T
Filters - Type Throwaway Throwaway
Furnished? Yes Yes
(No.) Size Recommended (3)20 X 20 X 2/(3)16 X 20 X 2
9
(2)20 X 20 X 2/(4)20 X 25 X 2
Refrigerant Charge (Lbs of R-22)
7
/Circuit 9.1/9.5
10
11.0/11.0
NOTES:
1. Cooling Performance is rated at 95°F ambient, 80°F entering dry bulb, 67°F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and
includes the effect of fan motor heat. Rated in accordance with ARI Standard 210/240 or 360
2. EER is rated at ARI conditions and in accordance with DOE test procedures.
3. Integrated Part Load Value is based On ARI Standard 210/240 or 360. Units are rated at 80°F ambient, 80°F entering dry bulb, and 67°F entering wet bulb at ARI rated cfm.
4. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards.
Ratings shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
5. AFUE and Steady State Efficiency is rated in accordance with DOE test procedures.
6. Sound Rating is rated in accordance with ARI Standard 270 or 370.
7. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
8. Face Area for Indoor Coil on Horizontal models is 12.36.
9. Horizontal Models have 4 -20 x 25 x 2 filters.
10. The refrigerant charge for Horizontal models is 7.8/8.1.
✲Indicates both downflow and horizontal units.
