15
Table 15-1 General Data
3 Ton Downflow Units 4 Ton Downflow and Horizontal Units
YC
✲037C3,C4 YC✲049C3,C4
Cooling Performance
1
Gross Cooling Capacity 42,400 51,400
SEER
2
12.00 12.00
Nominal CFM / ARI Rated CFM 1,200 / 1,200 1,600/1,600
ARI Net Cooling Capacity 41,000 49,500
System Power (KW) 3.78 4.61
Heating Performance
3
Heating Models Low High Low High
Heating Input (Btuh) 80,000 120,000 90,000 120,000
Heating Output (Btuh) 65,000 97,000 73,000 97,000
AFUE %
4
81.0 81.0 81.0 81.0
Steady State Efficiency (%) 81.0 81.0 81.0 81.0
No. Burners 1 1 1 1
No. Stages 1 1 1 1
Gas Connection Pipe Size (in.) 1/2 1/2 1/2 1/2
Compressor
No./Type 1/Climatuff® 1/Climatuff
Sound Rating (BELS)
5
8.2 8.2
Outdoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) OD 0.375 0.375
Face Area (sq ft) 11.32 11.32
Rows/FPI 2/16 2/16
Indoor Coil - Type Hi-Performance Hi-Performance
Tube Size (in.) 0.375 0.375
Face Area (sq ft) 6.33 6.33
Rows/FPI 2/15 3/15
Refrigerant Control Short Orifice Short Orifice
Drain Connection No./Size (in.) 1/3/4-PVC 1/ 3/4 PVC
Outdoor Fan - Type Propeller Propeller
No. Used/Diameter (in.) 1/24 1/24
Drive Type/No. Speeds Direct/1 Direct/1
CFM 4,100 4,100
No. Motors/HP 1/.25 1/.25
Motor RPM 850 850
Indoor Fan - Type FC Centrifugal FC Centrifugal
No. Used/Diameter (in.) 1/9 x 9 1/ 12 x 9
Drive Type/No. Speeds Direct/2 Direct/2
No. Motors 1 1
Motor HP (Standard/Oversized) .33/.40 .50/.75
Motor RPM (Standard/Oversized) 1075/1400 850/1040
Motor Frame Size (Standard/Oversized) 48/48 48/48
Filters - Type Throwaway Throwaway
Furnished? Yes Yes
(No.) Size Recommended (2) 20 X 25 X 1 (2) 20 X 25 X 1
Refrigerant Charge (Lbs of R-22)
6
8.30 8.90
NOTES:
1. Cooling Performance is rated at 95 F ambient, 80 F entering dry bulb, 67 F entering wet bulb. Gross capacity does not include the effect of fan motor heat. ARI capacity is net and
includes the effect of fan motor heat. Rated in accordance with ARI Standard 210/240 or 360
2. SEER are rated at ARI conditions and in accordance with DOE test procedures.
3. Heating Performance limit settings and rating data were established and approved under laboratory test conditions using American National Standards Institute standards. Ratings
shown are for elevations up to 2000 feet. For elevations above 2000 feet, ratings should be reduced at the rate of 4% for each 1000 feet above sea level.
4. AFUE and Steady State Efficiency is rated in accordance with DOE test procedures.
5. Sound Rating is rated in accordance with ARI Standard 270 or 370.
6. Refrigerant charge is an approximate value. For a more precise value, see unit nameplate and service instructions.
✲Indicates both downflow and horizontal units.
General 3
,,
,,
, 4 Ton
Data
High Efficiency
