Vertical Turbine Pumps
Pre-installation
Document Name: 2001299-VTP-IOM-EN Page 13 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
4.3 Uncrating and Cleaning
If the unit appears undamaged proceed to uncrate following the instructions given below:
• Clean all the parts of any dirt, packing material or other foreign matter.
• Flush the pump inside and outside with clean water or a fluid compatible with pumpage. If the pump is
for potable water, a lightly chlorinated flush may be recommended.
• Clean all machined surfaces as these are coated with a rust preventative before shipment, which must
be removed.
• Remove any rust spots found on the machined surfaces with a fine emery cloth.
• Clean all threaded connections and any accessory equipment.
4.4 Lifting
CAUTION
DEFLECTION OF THE PUMP
To prevent deflection of the pump components, take appropriate precaution to prevent the
weight of the pump from resting on the suction bell or case, when lifting to vertical position.
Refer to Figure 4-1 on page 15.
NOTICE
Parts and accessories may be placed inside shipping containers or attached to skids in
individual packages. Inspect all containers, crates and skids for attached parts before
discarding.
DANGER
LIFTING DEVICE SAFETY
• Use mechanical lifting devices to lift heavy or awkward components.
• Lifting devices must be in good condition, certified, and tagged.
• Lifting devices of adequate capacity must be used whenever they are required.
• Personnel must never work under suspended loads.
DANGER
LIFTING POINT SAFETY
Check that the lifting lugs are in suitable condition for lifting, before lifting pump parts.
WARNING
LIFTING EXPERIENCE
All lifting and rigging must be performed by qualified and experienced personnel who are
familiar with safe lifting practices and requirements. A lifting plan should be established and
followed to ensure safe lifting of all equipment.
WARNING
PERSONAL INJURY
To avoid personal injury, all components and assemblies greater than 30 lbs. (14 kg)
should be lifted using mechanical methods.
