Vertical Turbine Pumps
Installation
Document Name: 2001299-VTP-IOM-EN Page 24 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
10. Tighten the discharge (and suction, if applicable) flange bolting. Ensure that the flanges mate face to
face without applying excessive force.
11. Tighten the mounting flange bolting.
5.6 Hollow Shaft Driver Installation
1. Clean the driver mounting flange on the discharge head and remove any burrs or nicks on the register
and mounting face. Oil lightly.
2. Remove the driver clutch.
3. Clean the driver mounting flange and remove any burrs or nicks on the register and mounting flange. Oil
lightly.
4. Some electric motors are supplied with a lower guide bushing installed at the bottom of the motor to
stabilize the shaft at this point (also called a steady bushing). Some motor manufacturers mount this
guide bushing before shipping while others will ship the guide bushing separately with instructions for
field mounting. If applicable, mount the guide bushing to the motor (refer Figure 5-3 on page 25).
WARNING
PERSONNEL INJURY
• Always ensure proper tightening of all piping connections to the pump.
• Ensure the required gaskets and/or o-rings are installed.
• Poor connections may result in leakage.
• Leakage of hazardous or high pressure pumpage may result in personnel injury.
DANGER
LIFTING DEVICE SAFETY
• Use mechanical lifting devices to lift heavy or awkward components.
• Lifting devices must be in good condition, certified, and tagged.
• Lifting devices of adequate capacity must be used whenever they are required.
• Personnel must never work under suspended loads.
DANGER
LIFTING POINT SAFETY
Check lifting lugs are in suitable condition for lifting, before lifting pump parts.
WARNING
CONSULT DRIVER IOM MANUAL
Consult the driver IOM for all safety, installation, operation, maintenance and other product
information.
NOTICE
• All machined surfaces are coated with rust preventative prior to shipment. This must be
completely removed along with any paint overspray or rust which might be there on the
machined faces.
• The faces must be scraped and wire brushed first.
• Use fine emery cloth to remove any stubborn spots.
