Trillium FLOWAY - Figure 4-2:Fabricated Head Lifting; Figure 4-3:Cast Head Lifting; Figure 4-4:Typical Clamping Fixture

16 | IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
16 | IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
16 | IM-112 DECEMBER 2019
Vertical Turbine Pumps
2001299 - VTP- IOM
Vertical Turbine Pumps
Pre-installation
Document Name: 2001299-VTP-IOM-EN Page 16 of 67
Revision 3 Copyright © 2014, Weir Floway, Inc. All Rights Reserved. Issue Date: December 12, 2014
Figure 4-4: Typical Clamping Fixture
Figure 4-2: Fabricated Head Lifting Figure 4-3: Cast Head Lifting
Max. lift angle
from vertical
shall not
exceed 45°
Lifting devices must pass
through center opening of
top plate and wrap around
lifting lugs cast into the
vertical ribs
